Work with Air Compressor Hard Rock Drill

Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
  • After-sales Service：7*24 Online Service
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：30-50m
  • Bit Type：Drag Bit

Base Info

  • Model NO.：DFD-120Z
  • Drilling Way：Rotary
  • Type：Rotary Drilling Rig
  • Application：Hard Rock
  • Drilling Depth：30m
  • Drilling Caliber：90-140mm
  • Walk Speed：2.5km,H
  • Power：46,58kw
  • Usage：Hard Rock Drill, Water Well
  • Power Type：Diesel or Gasoline
  • Transport Package：Standard Container
  • Specification：4700x1950x2300mm
  • Trademark：DEFY
  • Origin：Henan, China
  • Production Capacity：100sets,Month

Description

HD120Z hard rock drill Work pressure(MPa)0.7~1.6Air consumption(m3/min)7~16Drill caliber(mm)90~140Drill depth(m)30Once promote distance(mm)2000Drill pipes diameter(mm)60/76Propeller compensate length(mm)860Max lifting strength(KN)28Skid up and down angle(°)Total 100Skid left and right angle(°)left20 right35drill arm up and down angle(°)30Climbing capacity(o)35Chassis clearance(mm)280Walk speed(Km/h)0~2.5Rotary speed(r/min)0~90Rotary torque(N.m)2000Power (Kw)46/58Applicable hardness(f)6~20Percussion frequency(r/min)950~1500Weight (Kg)4300dimension(mm)(length×width×high)4700×1950×2300
Working Site:
Work with Air Compressor Hard Rock Drill

Company

Work with Air Compressor Hard Rock Drill
Complete list of drilling rig and drilling tools for your project. For more details, please kindly send us an inquiry or contact our sales people directly. Thank you!

SALES MANAGER :  DEBBIE LIU
