Portable Borehole Drill Rig Supplier, Core Drilling Machine
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- After-sales Service：7*24 Online Service
- Certification：SGS, BV
- Condition：New
- Motor：AC Motor
- Drill Hole Diameter：250-300mm
- Drill Hole Depth：100-150m
Base Info
- Model NO.：XY-150
- Bit Type：Diamond Bit
- Drilling Way：Impactor
- Type：Rotary Drilling Rig
- Power：18HP
- Drilling Hole Diameter：400~75mm
- Stratum：Soil, Gravel, Weathered Stone, Concrete
- Power Type：Diesel
- Transport Package：as Requirement
- Specification：30-150m
- Trademark：DEFY
- Origin：China Mainland
- Production Capacity：50sets,Month
Description
1.Overall parameters
Drilling depth
150m
Maximum open hole caliber
400mm
End hole caliber
75mm
Diameter of drill rod
50mm
Drilling angle
90~75
Weight(not include power)
810kg
Dimension
2750*950*1600mm
2. Vertical shaft
Rotating speed
142, 285, 570 r/min
Feeding stroke
450mm
3.Hoist
Max. single line hoisting capacity
1600Kg
Diameter of wire rope
11mm
Volume of winding drum
27 m
Hug floodgate caliber
230mm
Hug floodgate belt width
50mm
4.Mud pump
Type
Horizontal single urn twin-action
Rate of flow
95/77L/min
MAX. pressure
1.2MPa
Working pressure
0.7MPa
5.Power
Diesel engine
18HP, 2000r/min
Electrical motor
11KW, 1460r/min
Packing and Delivery of XY-150 core Drilling Machine
Defy Service:
1.Professional technical support pre-sale, sale and after-sale .
2.Your problems can get feedback in 8 hours and be solved in 24 hours.
3.Machine can be customized as per your requirement.
4.One year quality warranty.
5.Training: operation manual and DVD operation video, overseas installation is also available.
6.Spare parts are available in our factory at cost price for former customers.
Complete list of drilling rig and drilling tools for your project. For more details, please kindly send us an inquiry or contact our sales people directly. Thank you!
SALES MANAGER : DEBBIE LIU
