400m Depth DTH Rock Water Well Bore Drill Boring Machine

Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
  • Certification：ISO 9001:2008, BV, SGS
  • Condition：New
  • Motor：AC Motor or Diesel Engine
  • Drill Hole Diameter：105-400mm
  • Drill Hole Depth：400m
  • Bit Type：DTH Bit

Base Info

  • Model NO.：DF-400S
  • Drilling Way：Impactor
  • Type：Crawler
  • Application：Water Well, Bore Well, Borehole
  • Color：Customized
  • Drill Depth：400m
  • Drill Diameter：115-400mm
  • Drill Pipe Length：3m
  • Power：56kw
  • Weight：8700kg
  • Lifting Force：68000n
  • Usage：Borehole, Bore Well, Water Well
  • Power Type：Diesel
  • Transport Package：Well Protected Container
  • Specification：400M DTH RIG
  • Trademark：DEFY
  • Origin：Henan, China
  • Production Capacity：100sets,Month

Description

DF-400S 400m water boring machine1Weight(Kg)90002Dimension(mm)5960×2150×26503Caliber(mm)115~3554Max depth(m)4005Walking speed(Km/h)0-2.56Grade ability(°)257Ground clearance(mm)3008Work pressure(MPa)1.6~2.469Air consumption(m³/min)16~3010Leg cylinder stroke(mm)160011Drilling speed(m/h)5-3012Diameter of the drill pipe(mm)76/89/10213Unit length of drill pipe(mm)300014Axial pressure(N)4600015Lifting force(N)9600016Hoist(N)1500017Lifting speed (slow)(m/min)818Lower speed (slow)(m/min)0.5~1619Lifting speed (fast)(m/min)3820Lower speed (fast)(m/min)8021Rotation speed(r/min)0~10022Rotary torque(Nm)650023Power(Kw)8524Apply for rock hardness(f)6~20
