Boart Longyear Standard Diamond Core Drill Rig for Sale
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- Condition：New
- Motor：DC Motor
- Drill Hole Diameter：Bq Nq Hq Pq
- Drill Hole Depth：500-1200m
- Bit Type：Diamond Bit
- Drilling Way：Rotary
Base Info
- Model NO.：DF-Y-42T
- Drilling Depth：500~1200m
- Drill Rod Diameter：42~89mm
- Power Supply：51HP
- Max. Torque：3.2 Kn.M
- I.D of Spindle：92mm
- Usage：Ore, Water Well, Coal
- Power Type：Diesel
- Type：Core Drilling Rig
- Transport Package：Standard Export Packing
- Specification：ISO; CE; BV; SGS
- Trademark：DEFY
- Origin：Henan, China
- Production Capacity：100 Sets Per Month
Description
Basic Info.
Model NO. DF-Y-42T Drilling Depth 500~1200m Drill Rod Diameter 42~89mm Power Supply 51HP Max. Torque 3.2 Kn.M I.D of Spindle 92mm Usage Ore, Water Well, Coal Power Type Diesel Type Core Drilling Rig Transport Package Standard Export Packing Specification ISO; CE; BV; SGS Trademark DEFY Origin Henan, China Production Capacity 100 Sets Per MonthProduct Description
DF-Y-42T Boart Longyear Standard Diamond Core Drill Rig for SaleDescription:
The DF-Y-42T core drill rig, integrated rig with tower into one unit, consists of DF-Y-42 drill rig and mast-type drill tower, with the function of hydraulic lifting and lowering of
tower.
Simple in structure, reasonable in design, light in weight, easy to operate; it is in a wide range
adjusting angle. It is especially suitable for drilling of hole with great slope angle.The tower body of DF-Y-42T Drill Rig is used as lifting drill tools for drilling vertical as well as inclined holes.
The range of adjusting angels (in clock-wise direction) for drilling inclined holes is 0°-90°.
Technical Specifications:
| Drilling Depth | 700-1100 m (2296~3608 feet) |
| Max. Torque | 3.2 KN·m(2358 lbf·ft) |
| Spindle Stroke | 600 mm (23.62 inch) |
| I.D of Spindle | 92 mm(3.62 inch) |
| Max. Lifting Capacity of Spindle | 80 KN(17984 lbf) |
| Max. Pressure Force of Spindle | 60 KN(13488 lbf) |
| Max. Hoisting Force | 30 KN(6744 lbf) |
| Engine Power | 30 KW(40HP) |
Our Service:
1. One year quality warranty.
2. Operation Manual or CD.
3. Free training; After-sale support works.
4. Accessories all year around.
5. Visit reception.
6. Volume-discount when order quantity is big.
