• Model NO.：ZLJ
• Max Feed Force Kn：9
• Max Pulling and Lining Force Kn：12
• Drilling Angle Degree：0~360°
• Capacity of Drum M：26.3
• Diameter of Wire Rope mm：8.8
• Drill Rod Caliber mm：42
• Supply Water Pressure MPa：0.6-12
• Power Kw：4
• Weight Kg：440
• Usage：Coal
• Power Type：Diesel
• Type：Rotary Drilling Rig
• Transport Package：Wooden Case
• Specification：CE
• Trademark：HW
• Origin：Shangdong China
• HS Code：8430411900
• Production Capacity：50000set,Year

Item
Unit
 Technical Parameter
ZLJ-250
ZLJ-350
ZLJ-650
ZLJ-400
ZLJ-700
Rated torque
High  speed

N·m

250
350
650
400
700
Medium  speed
150
250
380
230
520
Low  speed
85
100
214
130
310
Rated speed
High  speed

r/min

.
340
350
270
340
410
Medium  speed
192
170
151
192
198
Low  speed
112
99
88
112
150
Rated  pressure
Mpa
8
8
8
8
8
Max feed force
kN
9
9
34
9
34
Max pulling and lining force
kN
12
12
 12
12
12
Drilling angle
°
0~360°
0~360°
0~360°
0~360°
0~360°
Capacity of drum
m
26.3
26.3
40
26.3
40
Diameter of wire rope
Mm
8.8
8.8
11
8.8
11
Drill rod caliber
mm
42
42
42
42
42
Supply water pressure

Mpa
0.6~1.2
0.6~1.2
0.6~1.2
0.6~1.2
0.6~1.2
Power
kW
4
5.5
7.5
5.5
7.5
Voltage
V
380/660
380/660
380/660
380/660
380/660
Rated  current
A
8.8/5.3
9/13
15/10
13.4/8.8
17.1/11
Dimensions
mm
1235×630
×1165
1265×650
×1020
1200x1290
x700
1280×700
×1230

Weight
Kg
440
480
630
480
710




If you want more details about the machine specification and shipping packing details, contact me please:
Contacts: 0086-13583717630.
Lily song.
