Hydraulic DTH Hammer Mining Blast Hole Drill Rig Drilling Machine
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- Certification：ISO 9001:2008, BV, SGS
- Condition：New
- Motor：Diesel Engine or AC Motor
- Drill Hole Diameter：80-150mm
- Drill Hole Depth：30m
- Bit Type：DTH Bit
Base Info
- Model NO.：DFD-110Z
- Drilling Way：Impactor
- Max Depth：30m
- Max. Drilling Diameter(mm)：80~130mm
- Hardness Application：F=6~20
- Application：Mining Blast Hole Drilling Machine
- Weight(Kg)：3100
- Dimension(mm)：4400*1950*2150
- Working Pressure(MPa)：0.7~1.6
- Drilling Efficiency：Working with Air Compressor, Fast Drilling Speed
- Drill Tower up and Down Angle(°)：Total 100
- Drill Tower Left and Right Angle(°)：Left 20 Right 35
- Usage：Ore, Water Well, Coal, Blast Hole Drilling Machine
- Power Type：Diesel
- Type：Rotary Drilling Rig
- Transport Package：Container or Wooden Box
- Specification：ROCK BLASTING DRILL RIG
- Trademark：DEFY
- Origin：Zhengzhou, Henan Province
- Production Capacity：50 Sets
Description
DFD-110Z Hydraulic used DTH hammer mining blast hole drill rig drilling machine 1 Weight(Kg) 3100 2 Dimension(mm) 4400×1950×2150 3 Drill caliber(mm) 80~130 4 Drill depth(m) 30 5 Walk speed(Km/h) 2 6 Climb capacity(°) 30 7 Ground clearance(mm) 300 8 Working pressure(MPa) 0.7~1.6 9 Gas consumption(m³/min) 7 ~15 10 Stroke(mm) 2000 11 Sliding length(mm) 860 12 Drill tower up and down angle(°) Total 100 13 Drill tower left and right angle(°) Left 20 right 35 14 Power(Kw) 28/33/46 15 Hardness application F=6~20
Company Information:
ZhengZhou Defy 12 years professional exporting experience, realiable drilling machine manufacturer since 1970S.
Defy offer water well drilling machines drilling depth from 100m, 200m, 400m, 600m, 800m and 1500m. with 75-1500mm diameter. geotechnical core drilling machine from 0-3000m depth.
Spindle rotary type drilling machine, blast hole drilling machine, pneumatic air operated drilling machine, trailer, crawler, truck mounted drilling machine for your choices.
Our Service:
1. One year quality guarantee for main machine;
2. Training: operation manual, overseas installation is also available;
3. Spare parts are available in our factory at cost price for former customers;
4. 24 hour on-line guidance for operation and maintenance.
