100m Rock Borehole Drilling Rig Machine Prices
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- Certification:BV&SGS
- Condition:New
- Drill Hole Diameter:105-150mm
- Drill Hole Depth:100m
- Product Name:100m Rock Borehole Drilling Rig Machine Prices
- Application:Water Well, Geothermal Heat
Base Info
- Model NO.:DFQ-100W
- Color:White
- Power:24kw,2300rpm
- Walking Speed:0~1.5km,H
- Chassis:Two Wheels
- Transport Package:Standard Container
- Specification:3200X1770X2050 mm
- Trademark:DEFY
- Origin:Henan, China
- Production Capacity:150 Sets Per Month
Description
No.
Item
Parameter of Drilling Rig
1
Drilling caliber
Φ105-150mm
2
Max. drilling depth
100m
3
Diameter of drill pipe
Φ76
4
Gas consumption
15-18 m³/min
5
Power
24Kw/2300rpm
6
Walking speed
0~1.5Km/h
7
Leg cylinder stroke
600 mm
8
Propulsion
5.0 tonf
9
Lifting force
8.5 tonf
10
Speed of spindle
Fast 135 rpm Slow 91 rpm
11
Rotary torque
1050N.m
12
Weight
2200Kg
13
Dimension
3200×1770×2050 mm
Exhibition Photos
Packaging & Shipping
Packing: Standard export packing or as your requirement.
Shipping: DHL/UPS/TNT/FEDEX,By Air,By Sea.
Delivery: 10-15 working days against payment.
Payment terms
T/T,L/C,Western Union,Pay Pal,etc.
Our Service
1. Provide factory cost accessories all year
2. Engineers are available to service machine overseas or free training in factory
3. Online service 24hours*7 days
4. 12 months quality warranty for main body
