Drilling Machines for Rigs Borehole Drilling Machine Price From China

Tianjin Henghua Pipeline Technology Co., Ltd.
  • Certification：CE, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：DC Motor
  • Drill Hole Diameter：50-150
  • Drill Hole Depth：200
  • Bit Type：Diamond Bit

Base Info

  • Model NO.：HH180Y
  • Drilling Way：Impactor
  • Type：Water Well Drilling
  • Power Type：Diesel
  • Usage：Coal, Ore, Water Well, Geotechnical Investigation
  • Voltage：380V
  • Power (W)：13.2
  • Dimension：2400*800*140
  • Weight Without Power：620kgs
  • Warranty：12 Months
  • After-Sales Service：Overseas 3-Party Support
  • Dilling Depth：180m
  • Drill Rod Dia.：42-60mm
  • Transport Package：Standard Export Wooden Carton or Costomized
  • Specification：2400x800x1300mm
  • Trademark：OEM
  • Origin：China (Mainland)
  • HS Code：8412412900
  • Production Capacity：5000 Sets Per Month

Description

ModelHZ-130Y/130YY

HZ-180Y/180YY

HZ-200Y/200YY Drilling depth(m)130180200 Open hole dia.(mm)220220325End hole dia.(mm)757575Drill rod dia.(mm)42-6042-6042-60drill angle(°)90-7590-7590-75 Matching power(kW)13.213.215Weight without power(kg)600/740620/750880/970 Dimension Length*width*height(mm)2.4*0.7*1.42.4*0.6*1.42.7*0.9*1.6Vertical shaft speed(r/min)142/285/570130/300/480/730/830/104564/128/287/557Vertical axis stroke(mm)450450450 Max Single rope lifting force(kg)200021002500Single rope lifting speed(m/min)0.41-1.640.35-2.230.12-0.95Wire rope diameter(mm)φ9.3φ9.3φ12.5Wire rope capacity(m)273535Rated load(ton)181818effective height(m)6.56.56.5 Dispalcement(L/min)9595145 Max.pressure(Mpa)1.21.22Number of reciprocations(Times/min)939393Diameter of suction pipe(mm)515151Outlet diameter(mm)323238Drilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From ChinaDrilling Machines for Rigs Borehole Drilling Machine Price From China

Drilling Machines for Rigs Borehole Drilling Machine Price From China
FAQ..................

Question 1: What are your advantages compared with your competitors?

Answer:

With rich industry experience and strict Product Quality Control systems, we provide:

1). Stable and reliable product at reasonable price

2). Good customer service: Fast response to any inquiry or question

3). On-time delivery.



Question 2: Can you customize the machine for me ?

Answer: Yes, we can customize according to customer's requirements.



Question 3: What shall we do if breakdown occurs?

Answer: Please informed us once the breakdown occurs. During warranty period, if breakdown occurs, we shall respond in time after receiving the notification of the buyer. We shall handle failure over the telephone/ fax or arrange relevant personnel to the site according to the buyer's requirements.
