Trailer Hydraulic 600m Water Well Drilling Rig Machine
Ji Ning Hengwang Mining Machinery Co., Ltd.- Certification：CE, ISO 9001:2000
- Condition：New
- Motor：AC Motor
- Drill Hole Diameter：250-300mm
- Drill Hole Depth：600m
- Bit Type：Diamond Bit
Base Info
- Model NO.：HW
- Drilling Way：Rotary
- Type：Rotary Drilling Rig
- Name：Water Well Drilling Rig
- Drilling Depth：600m
- Maximum Open Hole Caliber：260m
- End Hole Caliber：75mm
- Drill Rod Caliber：50mm
- Drilling Angle：90-75
- Diesle Engine Power：18HP
- Mud Pump：Bw Mud Pump
- Drilling Rig Weight：560kg
- Power Type：Diesel
- Transport Package：Wooden Case or According to Customer′s Demands
- Specification：CE,ISO
- Trademark：HW
- Origin：Shangdong China
- HS Code：8430412100
- Production Capacity：50000set,Year
Description
Mud pump
Type
Horizontal single urn twin-action
Displacement
95/77L/min
Diesle engine
Model s1110 18HP
Electric motor
Y160M-4 11kw 1440r/min
Maximum pressure
1.2Mpa
Work pressure
0.7Mpa
Water inlet caliber
30mm
Water to exit caliber
25mm
Triangle conveyor belt
B1575mm
