Crawler Integrated DTH Surface Mine Drilling Rig
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE, ISO 9001:2000
- Condition：New
- Motor：Yuchai
- Drill Hole Diameter：80-115mm
Base Info
- Model NO.：30M
- Drill Hole Depth：20m
- Bit Type：Diamond Bit
- Drilling Way：Impactor
- Model：Hw421t
- Power：Yuchai Yc6j220 162 Kw
- Hole Depth：20m
- Drill Pile Sizes：60 Mmx3000 mm
- Hole Dia：80-115mm
- DTH Hammer：3.5"
- Rotation Torque (Max.)：1650n.M
- Rotation Speed：0-110 Rpm
- Working Pressure：14.5 Bar
- F.a.D：12 M3,Min
- Tramming Speed (Max.)：2,3 Km,H Dual Speed
- Gradient：30°
- Total Weight：6,800 Kg
- Transportation Dimensions：6,000X2,800X2,750 mm
- Dry Dust Collector：Standard
- Specification：6, 000X2, 800X2, 750 mm
- Trademark：Hengwang
- Origin：China Shandong
- HS Code：8430419000
- Production Capacity：1000 Sets Per Month
Description
Main technical specifications
Power
Yuchai YC6J220 162 kW
Hole Depth
20m
Drill Pile Sizes
60 mmX3000 mm
Hole Dia
80-115mm
DTH Hammer
3.5"
Rotation Torque (Max.)
1650N.m
Rotation Speed
0-110 rpm
Working Pressure
14.5 bar
F.A.D
12 m3/min
Tramming Speed (Max.)
2/3 km/h Dual Speed
Gradient
30°
Track Frame Oscilation
±10°
Total Weight
6,800 kg
Transportation Dimensions
6,000X2,800X2,750 mm
Dry Dust Collector
Standard
Dual Speed Walking Motor
Standard
