Geothermal Borewell Drilling Rig Machine

Henan Yugong Machinery Co., Ltd.
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Motor：DC Motor
  • Drill Hole Diameter：140-350mm
  • Drill Hole Depth：400m
  • Bit Type：Diamond Bit

Base Info

  • Model NO.：bore well drilling machine
  • Drilling Way：Impactor
  • Type：Crawler
  • Transport Package：Container
  • Specification：5050*2100*2800mm
  • Trademark：YUGONG
  • Origin：Henan, China
  • HS Code：8433901000
  • Production Capacity：100sets,Month

Description

Basic Info.

Model NO. bore well drilling machine Drilling Way Impactor Type Crawler Transport Package Container Specification 5050*2100*2800mm Trademark YUGONG Origin Henan, China HS Code 8433901000 Production Capacity 100sets/Month

Product Description

Geothermal Borewell Drilling Machine
Application: widely applied in industrial and civil water well drilling, geothermal well drilling, with large diameter, deep hole, fast speed, flexiable operatoin, high efficiency and other advantages.
Geothermal Borewell Drilling Rig Machine
Main Parameters
Weight: 10T
Dimension: 5050*2100*2800mm
Hope Dia.: 140-350mm
Hole Depth: 400m
Feed Stroke: 6600mm
Walking Speed: 2.5km/h
Min. Distance above the Ground: 250mm
Working Pressure: 1.7-3.5Mpa
Air Consumption: 17-35m³/min
Main Motor Power: 95kw
Rotary Speed: 45-115rpm
Rotary Torque: 8500-10000N.m
