• Model NO.：SWDHD726
• Drilling Way：Impactor
• Drilling Depth：25 M
• Rock Rigidity：F=6-20
• Weight：4500 Kg
• Warranty：One Year
• Transport Package：Naked
• Specification：4500kg
• Trademark：Sinoway
• Origin：China
• HS Code：8430412900
• Production Capacity：300 PCS,Month

EngineCompressorModelCummins 6BT5.9TypeSix-cylinder, water cooled, turbocharged, mechanical injectionRated power110kwRated speed2200rpmMain Technical SpecificationTracked drilling CarriageRock rigidityf=6 - 20Diameter of drill hole60 - 130mmDepth of drill hole25mTravelling speed3km/hGradeability25°Rotation speed0 - 70rpmWorking pressure0.5 - 1.4MPaAir consumption7 - 12m³/min.CompressorTypeScrew rotating one stage compression oil cooledDisplacement10.2m³/min.Pressure0.7 - 1.0MPaLubricating modeForced lubricating according to lubricating compressionDrive modeCoupler directVolume of lubricating oil60LChassisCompressorTyre size6.5-16Tyre pressure0.6MPaTread1560mmDimensionsTracked drilling CarriageOverall length4250mmOverall width1980mmOverall height2260mmCompressorOverall length3360mmOverall width1850mmOverall height1850mmConnector sizeR1.1/2"x1, R1"x2Max. working altitude3000mWeightTracked drilling Carriage3000kgCompressor2100kgMain FeaturesTracked drilling CarriageSelf-powered high efficiency, energy saving, lower noise, less operation cost, wide range of usage, easy for maintenance, major components such as motor / control valve made in Germany and Japan, large scope amplitude modulation capacity.CompressorAdvanced microprocessor monitoring all changes for compressed air demand, lowering air consumption, motor / mounted roller / ball bearing made in Germany; advanced separator and filter insuring residual oil content less than 3ppm, aluminium radiator easy for cleaning, anti-high temperature pipe and connector prevent oil leakage.Optional10 - 20m³/min. air delivery compressor series Depth of drill hole with 30m / 35m Drilling diameter90 - 130mm
