Integrated DTH Surface Drill Rig Hot Sale
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE, RoHS, ISO 9001:2008
- Condition：New
- Motor：Yuchai
- Drill Hole Diameter：90-138mm
Base Info
- Model NO.：HW453
- Drill Hole Depth：20m
- Bit Type：Diamond Bit
- Drilling Way：Impactor
- Model：Hw453
- Engine：Yuchai Yc6l260-H300
- Hole Range：90-138 mm
- Drill Pipe Storage：7+1
- Drill Pipe Diameter：76X3,000 mm
- DTH Hammer：DTH Hammer
- Rotation Torque ( Max.)：2,800 N.M
- F.a.D：16 M3,Min
- Working Pressure ( Max.)：17 Bar
- Pull up Force ( Max.)：31 Kn
- Tramming Speed ( Max.)：3 Km,H (High Speed)
- Gradient：30°
- Track Frame Oscilation：±10°
- Total Weight：15,000 Kg
- Transportation Dimensions：9,000X2,300X3,000 mm
- Specification：9, 000X2, 300X3, 000 mm
- Trademark：HW
- Origin：Shandong
- Production Capacity：100PCS ,Month
Description
Model
HW453
Engine
Yuchai YC6L260-H300 191kW@2,150rpm
Yuchai YC6L260-H300 191 kW @ 2,150 rpm
Hole Range
90-138 mm
Drill Pipe Storage
7+1
Drill Pipe Diameter
76X3,000 mm
DTH Hammer
4"
Rotation Torque ( Max.)
2,800 N.m
F.A.D
16 m3/min
Working Pressure ( Max.)
17 bar
Pull Up Force ( Max.)
31 kN
Tramming Speed ( Max.)
3 km/h (High Speed)
2 km/h (Low Speed)
Gradient
30°
Track Frame Oscilation
±10°
Total Weight
15,000 kg
Transportation Dimensions
9,000X2,300X3,000 mm
