• Model NO.：XY-400C
• Drilling Way：Rotary
• Type：Rotary Drilling Rig
• Depth：100~400m
• Diameter：600mm~75mm
• Application：Soft Mud to Hard Rock
• Used for：Core Sampling, Water Wells
• Work with：Mud Pump
• Drill Bit：Diamond Core Bit, Tricone Bit
• Usage：Water Well
• Power Type：Diesel
• Transport Package：Standard Export Packing
• Specification：BV&SGS&ISO
• Trademark：DEFY
• Origin：Henan, China
• HS Code：8432490000
• Production Capacity：60 Sets,Month

1. Main ParametersMax. Drilling Depth400mDiameter of drill pipeΦ42,Φ50,Φ60,Φ76Angle of vertical spindle0°~90°Drilling capabilityΦ75mm drill diameterMax. Depth 400mΦ168mm drill diameter
  Max. Depth 220mΦ273mm drill diameterMax. Depth 130mΦ400mm drill diameterMax. Depth 100mΦ600mm drill diameterMax. Depth 30m  2. Vertical SpindleRotation speedForward 8 grades50-1150r/minReverse 2 grades29-137r/minSpindle stroke600mmSpindle bore62mmHoisting capability6000kgMax. Torque2800N.m3. Main hoistLifting speed of single wire0.5-1.9m/sDiameter of wire rope14.0mmCarry capacity of single wire4000kgDiameter of winding drum300mmVolume of winding drum50mLifting capability of single wire3000kg4.Auxiliary Hoist Winding drum140mmDiameter of steel wire rope6mmVolume of winding drum450m5. Mud pump(as per your choice)Horizontal triplex mud pumpBW-200IIDisplacement200L/minWorking pressure50kg/cm² @ 5MPaDiameter of water inlet hose65mmDiameter of water outlet hose38mm6.Power supply(choose one between the following two)Diesel engine17.6kw (24HP)Electrical motorY160L-4,18.5kw
Disassemble drill tower;
Small in size.XY-13075~300mm130mXY-15075~400mm150mXY-18075~400mm180mXY-20075~400mm200mXY-200F75~400mm200mMounted on TrailerXY-200C75~400mm200mMounted on CrawlerXY-400F75~600mm400mMounted on TrailerXY-400C75~600mm400mMounted on CrawlerXY-600F75~600mm600mMounted on TrailerXY-600C75~600mm600mMounted on Crawler
