Made in China Machine Core Bit Drill High Frequency 130m Core Sampling

Shandong Beijun Heavy Industry Co., Ltd.
  • Certification：CE
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：150-200mm
  • Drill Hole Depth：100-150m
  • Bit Type：Diamond Bit

Base Info

  • Model NO.：HZ-130Y
  • Drilling Way：Rotary
  • Drilling Depth：130m
  • Maximum Open Hole Caliber：220mm
  • End Hole Caliber：75mm
  • Drill Rod Caliber：50mm
  • Drilling Angle：90-75°
  • Drill Weight (Not Include Power)：750kg
  • Spindle Speed：142 285 570r,Min
  • Spindle Stroke：450mm
  • Max.Single Line Hoisting Capacity：1600kg
  • Single Line Lifting Speed：0.41,0.82,1.64m,S
  • Transport Package：Wooden Packaging
  • Specification：750kg
  • Trademark：Beijun
  • Origin：Shandong
  • Production Capacity：1000 Set a Month

Description

Mud pumpTypeHorizontal single urn twin-actionElectric motor95/77 l/minMaximum pressure1.2mpaWork pressure0.7mpaWater inlet caliber30mmWater to exit caliber20mmTriangle conveyer beltB1575mmMade in China Machine Core Bit Drill High Frequency 130m Core Sampling
