Xy-100 100m Core Drill with Accessories in Tanzania
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- After-sales Service：7*24 Online Service
- Certification：ISO 9001:2000
- Condition：New
- Motor：AC Motor
- Drill Hole Depth：<100m
- Bit Type：Diamond Bit
Base Info
- Model NO.：XY-100
- Drilling Way：Rotary
- Power：15HP
- Application：Water Well, Coring, Soil Testing, etc.
- Drilling Hole Diametert：300~70mm
- Stratum：Soil, Gravel, Weathered Stone, Concrete
- Color：as Requirement
- Usage：Ore
- Power Type：Diesel
- Type：Rotary Drilling Rig
- Transport Package：Wooden Package
- Specification：SGS, BV
- Trademark：DEFY
- Origin：Henan, China
- HS Code：84304900
- Production Capacity：50 Sets Per Month
Description
1.Overall parameters
Drilling depth
100m
Maximum open hole caliber
300mm
End hole caliber
75mm
Diameter of drill rod
42mm
Drilling angle
90~75
2. Vertical shaft
Rotating speed
142, 285, 570 r/min
Feeding stroke
450mm
3.Hoist
Max. single line hoisting capacity
1600Kg
Diameter of wire rope
11mm
4.Mud pump
Type
Horizontal single urn twin-action
Rate of flow
95/77L/min
5.Power
Diesel engine
18HP, 2000r/min
Electrical motor
11KW, 1460r/min
Remarks: Dear friend, thank you for your time! We are professional manufactuer of drilling rig and tools, and we have a top expert team for before&after sale technical support. So please feel free to inform me your drilling depth (m) and caliber (mm), our engineers will design a complete suitable configuration list for you!
