Zega D545 Crawler Type Integrated DTH Surface Drilling Rig

Changsha Miracleland Import & Export Co., Ltd.
  • Certification：ISO 9001:2008
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：108-127mm
  • Drill Hole Depth：20m
  • Bit Type：DTH Bit

Base Info

  • Model NO.：D545 Crawler Integrated DTH Surface Drilling Rig
  • Drilling Way：DTH Hammer
  • Drill Pipe Type：76mm
  • Engine Manufacturer：Cummins
  • Usage：Ore, Pile Foundation Hole, Coal
  • Power Type：Diesel
  • Type：Rotary Drilling Rig
  • Transport Package：Plastic Film
  • Specification：545
  • Trademark：ZEGA
  • Origin：China
  • HS Code：8430490000
  • Production Capacity：10, 000PCS,Year

Description

D545 Technical SpecificationsEngine ManufacturerCumminsEngine Model6BTA8.3-C260Engine Rated Power194 kWEngine EmissionEuro IIF.A.D15 m3/minWorking Pressure17 BarRotation Speed0-90 rpmRotary Torque2479 NmHole Diameter RangeØ108-127 mmDTH Hammer4 inchHole Depth20 mNumber of Pipes6+1Drill pipe type76 mPipe Length3,000 mm(collaring 2000 mm)Feed TypeCylinder / ChainLength of Feed Beam5,340 mmFeed Extension1200 mmFeed Travel Length3,200 mmFeed SpeedFeed ForcePull Up Force(Max.)40 kNMax. Climbing Ability25°Feed Force(Max.)21 kNTramming Speedhigh 3 km/h,low 2 km/hTraction Force( Max.)71 kNGround Clearance360 mmFuel Tank Capacity420 LLength7,150 mmWidth2,500 mmHeight2,800 mmWeight(options excluded)10,500 kg
Zega D545 Crawler Type Integrated DTH Surface Drilling Rig
