Pneumatic Rock Drill/Air Drill Yt29A
Fuzhou Golden Moral Imp & Exp Co., Ltd.- Condition：New
- Motor：Optional
Base Info
- Model NO.：YT29A
- Drill Hole Diameter：>300mm
- Drill Hole Depth：<100m
- Bit Type：Optional
- Drilling Way：Impactor
- Certificate：Ce
- Transport Package：Wood and Cartons
- Specification：CE, OEM
- Trademark：GM
- Origin：China
- Production Capacity：5000unit,Year
- Package size per unit product：73.00cm * 30.00cm * 22.00cm
- Gross weight per unit product：32.000kg
Description
Basic Info.
Model NO. YT29A Drill Hole Diameter >300mm Drill Hole Depth <100m Bit Type Optional Drilling Way Impactor Certificate Ce Transport Package Wood and Cartons Specification CE, OEM Trademark GM Origin China Production Capacity 5000unit/YearPackaging & Delivery
Package size per unit product 73.00cm * 30.00cm * 22.00cm Gross weight per unit product 32.000kgProduct Description
Pneumatic rock drill YT29A:YT29A rock drill is the most strongest, powerful and highly efficient rock drill in the range.It gives improved productivity and drill steel economs and can be used on all rock formation and in all kinds of applications.
Specification:
Weight 26 KG
All length 660MM
Air consumption ≤82L/S
Drilling Frequency ≥40HZ
Air pipe inner Dia. 25MM
Water pipe inner Dia. 13MM
Drilling Hole Dia. 34-42MM
Drilling Depth 5M
Shank Size 22*108mm
Air pressure 0.63Mpa
FT160 Air leg:
Weight 17KG
Length 1800MM
Pushing stroke 1370MM
FY250 Oil Reservior:
Weight 1.2KG
Oil capacity 250ML
