Drilling Depth High Quality Mobile Water Well Drilling Rig Machine Hqz-260L for Sale

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Certification：CE
  • Condition：New
  • Motor：Diesel Engine
  • Drill Hole Diameter：250-300mm

Base Info

  • Model NO.：260m
  • Drill Hole Depth：>200m
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary
  • Type：Crawler
  • Dimensions(L*W*H)：6147X3633X6637mm
  • Machine Weight：6850kg
  • Rated Power：73kw
  • Drill Depth：260m
  • Drill Diameter：100-300mm
  • Engine：Yuchai,Yunnei
  • Transport Package：Container
  • Specification：8 t
  • Trademark：HW
  • Origin：China
  • Production Capacity：60 Set,Sets Per Month

Description

Model

HQZ-260L

Total Weight(T)

6.4

Dimensions(mm)

4100*1900*2600

Drilling Diameter(mm)

140-300

Drilling Depth(m)

260

One-time Advance Length of the Drill(mm)

3000

Walking Speed(Km/h)

2.5

Climbing Ability(max)

30

Min. Ground Clearance(mm)

250

Working Air pressure(Mpa)

1.7-3.0

Air Consumption(m³/min)

17-35

Main Power(kw)

73/Yuchai

Rotation(rpm)

40-70

Rotary Torque(Nm)

7000-9000


 Detail Photos

Drilling Depth High Quality Mobile Water Well Drilling Rig Machine Hqz-260L for SaleDrilling Depth High Quality Mobile Water Well Drilling Rig Machine Hqz-260L for SaleDrilling Depth High Quality Mobile Water Well Drilling Rig Machine Hqz-260L for SaleProduct ConfigurationSuccessful ProjectPackaging&ShippingDrill rigs are coated with anti-rust liquid naked, drill pipes are bundled and packed, impactors, drill bits and other accessories are packed in plywood boxes.1 Set Shipped with 20GP;
Whole set with air compressor needs a 40GP;
