Gold Mine Blasting Hole Drilling Rig

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • After-sales Service：Yes
  • Warranty：Yes
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：Diesel Engine
  • Drill Hole Diameter：<100mm

Base Info

  • Model NO.：HW421
  • Drill Hole Depth：<100m
  • Bit Type：Diamond Bit
  • Drilling Way：Impactor
  • Operating Weight：6850kg
  • Dimensions(L*W*H)：6000X2800X2750mm
  • 6000X2800X2750mm：162kw
  • Drill Depth：20m
  • Hole Diameter：80-115mm
  • Air Comrpessor Size：14.5bar
  • Transport Package：Roro Ship
  • Specification：6800kg
  • Trademark：HW
  • Origin：China
  • HS Code：8430509000
  • Production Capacity：600 Set,Sets Per Month

Description

                                       air compressor built-in  surface DTH mine drilling rig for quarry                                                                                     ModelHW421Machine Weight6800kgEngineYuchai  162 kWDrill Pipe Sizes60 X 3,000 mmHole Dia80-115 mmWorking Pressure15 barF.A.D12 m3/minTramming Speed ( Max.)3 km/h (High Speed)Gradient25°Track Frame Oscilation±10°Transportation Dimensions6000X2800X2750 mm
Detailed Images


Gold Mine Blasting Hole Drilling Rig
High Quality gold mine drilling machine and Durable.
Gold Mine Blasting Hole Drilling Rig

Gold Mine Blasting Hole Drilling Rig

Construction Site of  open pit mine drilling machineGold Mine Blasting Hole Drilling Rig
