Competitive Price Gl-II Truck Mounted Drilling Rig

Glorytek Industry (Beijing) Co., Ltd.
  • Certification：CE
  • Condition：New
  • Motor：Diesel Engine
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：100-150m
  • Bit Type：Drag Bit

Base Info

  • Model NO.：GL-II
  • Drilling Way：Compound
  • Type：Truck
  • Item：Gl - Iitruck Mounted Drill
  • Hole Diameter (Mm)：90-1200
  • Hole Depth (M)：150
  • Run of Rod (M)：3
  • Rig Mass (Kg)：9100
  • Drilling Technology：Normaland Reverse Circulation for Both Mud and Air
  • Down-The-Hole Hammers：Middle-High-Pressure Air
  • Drill Head Lifting Force(Kn)：94.55
  • Feed Thrust (Kn)：0-12
  • Main Hoist Lifting Force (Kn)：18.54
  • Transport Package：Standard Export Packing
  • Specification：SGS
  • Trademark：GLORYTEK
  • Origin：China
  • Production Capacity：50 Sets Per Month

Description

Drill Head Spin Speed (r/min) :A(Forward:13-22-48, Reverse:10-17-36)B(Forward: 48-84-184, Reverse: 37-65-142)Main Hoist Lifting Force (kN):18.54Mud Pump:BW450Flow (L/min):450 350Pressure: (Mpa)1.2 2.0Power Unit:Diesel EnginePower(Kw):42Supporting FormHydraulic UnitMask Up-Down:Hydraulic UnitChassis:DONG FENG EQ1093(four-wheel drive)Dimensions(mm): (L-W-H)Working Conditions: 7900*2370*7200Transport status: 8450*2370*3400Competitive Price Gl-II Truck Mounted Drilling Rig
