Type Ytr180b Rotary Drilling Rig
Glorytek Industry (Beijing) Co., Ltd.- Certification:ISO 9001:2008
- Condition:New
- Drill Hole Diameter:>300mm
- Drill Hole Depth:30-50m
- Bit Type:Bucket
- Drilling Way:Rotary
Base Info
- Model NO.:YTR180B
- Type:Crawler
- Max. Drilling Depth(M):65
- Max. Drilling Diameter(mm):1500
- Output Torque (Kn.M):180
- Goss Weight (Including Standard Drilling:56.5
- Weight Under Transport State(T):47.2
- Traction Force(Kn):370
- Collocating Power(Kw):246
- Rotating Speed of Power Unit (Rpm):125,133
- Max.Boosted Pressure (Kn):150
- Max. Lifting Force (Kn):160
- Noise:Without Noise
- Transport Package:Standard Packing
- Specification:ISO9001
- Trademark:Glorytek
- Origin:Beijing China
- Production Capacity:100 Sets Per Month
Description
Basic Info.
Model NO. YTR180B Type Crawler Max. Drilling Depth(M) 65 Max. Drilling Diameter(mm) 1500 Output Torque (Kn.M) 180 Goss Weight (Including Standard Drilling 56.5 Weight Under Transport State(T) 47.2 Traction Force(Kn) 370 Collocating Power(Kw) 246 Rotating Speed of Power Unit (Rpm) 125/133 Max.Boosted Pressure (Kn) 150 Max. Lifting Force (Kn) 160 Noise Without Noise Transport Package Standard Packing Specification ISO9001 Trademark Glorytek Origin Beijing China Production Capacity 100 Sets Per MonthProduct Description
Name: YTR180B Rotary Drilling RigKey words: Rotary drilling rig; Rotary drill rig; Piling drilling rig; Piling machine; Drill rig
Description of YTR180B Rotary Drilling Rig:
Our rotary drilling rig absorbs the advantages of domestic and foreign famous brand products in design and techniques whose major performance parameter has reached international level of the similar product and whose components all adopts international famous brand products to guarantee the reliability of complete machine. It can be matched with drilling tools such as short spiral bit, common drilling bucket, and bailing drilling bucket etc. And can be drilled into clay layer, gravel bed, pebble bed and weathered mudstone bed. It has advantages such as high working performance, strong site adaptability, and obvious environmental protection effect., and is widely used in the pile foundation construction of railway and roadway bridges, urban traffic construction, and high-rise buildings etc, and also is the high efficiency drilling equipment for large and medium pile foundation engineering construction.
Product model parameter | YTR280 | YTR260B | YTR220 | YTR180B |
Max. drilling depth(m) | 90 | 80 | 68 | 65 |
Max. drilling diameter(mm) | 2200 | 2000 | 2000 | 1500 |
Output torque (kN.m) | 280 | 260 | 220 | 180 |
Rotating speed of power unit (rpm) | 6.5-29 | 41118 | 41113 | 7-32 |
Max.boosted pressure (kN) | 215 | 190 | 190 | 150 |
Max. lifting force (kN) | 230 | 230 | 196 | 160 |
Left/right tilting angle of mast(°) | 3.5 | 3.5 | 3.5 | 3.5 |
Forwarding tilting angle of mast(°) | 3.5 | 3 | 3 | 3 |
Engine manufacturer and model | C9ACERT EFI(Optional 1: Doosan; Optional 2: Commins) | Commins QSM11-C330 | Commins6C8.3/ 6CTA8.3 (Optional: Caterpillar) | Commins 6BTA5.9-C169/B5.9C |
Collocating power(kw) | 260 | 246 | 186/194 | 125/133 |
Lifting force of main winch (kN) | 270 | 240 | 240 | 170 |
Diameter of steel rope of main winch(mm) | 32 | 28 | 28 | 26 |
Max. lifting speed of main winch(m/min) | 80 | 77 | 70 | 65 |
lifting force of auxiliary winch (kN) | 120 | 120 | 120 | 50 |
Diameter of steel rope of auxiliary winch(mm) | 20 | 20 | 20 | 16 |
Max. lifting speed of auxiliary winch(m/min) | 70 | 70 | 70 | 56 |
Chassis model | CAT 336D (Optional1: Doosan; Optional2: Bonny) | Bonny | Bonny (Optional: Caterpillar) | Bonny |
Traction force(kN) | 270 | 410 | 390 | 370 |
Goss weight (including standard drilling tool)(t) | 80 | 78 | 73 | 56.5 |
Weight under transport state(t) | 68 | 67 | 63 | 47.2 |
