• Model NO.：EB2935
• Drill Hole Depth：100-150m
• Bit Type：Cone Bit
• Drilling Way：Rotary
• Transport Package：Bulk or Wooden Case
• Specification：3030x1100x1890mm
• Trademark：EB
• Origin：China
• Production Capacity：30sets,Year

Drilling Capacity:Core DrillSorts of Drill RodDrill Rod Spec.(mm)Drilling Depth(m)Home Made Drill RodPlaner In and OutΦ43×61500Φ54×61100Φ67×6930Thickened InnerΦ50×5.51400Φ60×61050Extracting Core with Wire LineΦ55.5×4.751500Φ71×51100Φ89×5900DCDMA (Diamond Core Drill Manufacturer Association) Made Drill RodThickened InnerBW1350NW1100HW760Extracting Core with Wire LineBQ1500NQ1200HQ850Basic SpecificationsDrilling Angle0~360°Dimension(L×W×H)3030×1100×1890mmWeight(Without Power Unit)2150KgRotary HeadI.D of Spindle93mmRotary Speed of Spindle(Power Speed is 1480r/min)Forward80;148;212;247;308;456;650;945Reverse66;201Max.Torque of Spindle4300N·mFeeding Stroke600mmMax.Feeding Capacity90KNMax.Lifting Capacity120KNHoistMax.Lifting Capacity(Single Line)45KNLifting Speed0.7;1.29;1.84;2.68m/sDiameter of Steel Wire Rope17.5 or 18.5mmCapacity of Drum110 or 90mWater BrakeWork Rotary Speed700-1800r/minSingle Balance Speed3-8m/sSingle Balance Load45KNOil PumpModelSingle Gear Oil PumpPressure,Displacement20MPa, 20ml/rPower UnitR4105ZG4(Diesel Engine Model R4105ZG4)62KW,2000r/minY225M-4(Electric Motor Model Y225M-4)45KW,1480r/min



Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5~10 days if the goods are in stock.Or it is 45 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
irrevocable LC at sight.
