China Brand Xmz130 Anchor Drilling Rig Crawler Mobile Drilling Rig

Sinomada Heavy Industry (Changsha) Co., Ltd.

Condition：New
Drilling Way：Rotary
Type：Crawler
Transport Package：Nude Package
Specification：2250x3040x2500
Origin：China

Base Info

Model NO.：XMZ130
Production Capacity：100 Units,Month

Description

DescriptionUnitDataEngineModel QSB6.7-C170Rated power/speedkW129/2200r/minMax. TorqueN·m800/1400Fuel tank capacityL340Rotary headModel Euro Drill HD5012low operationMax. torqueN·m14100Rotary speedr/min39Fast operationMax. TorqueN·m7050Rotary speedr/min78Vibration powerN·m650Vibration frequencymin-12300Hydraulic systemMain pump Max. pull-down piston pushMpa25Main pumpL/min176+129Auxiliary pumpL/min43Hydraulic oil tank capacityL450Hoist & Feed
systemFeed type JackFeed strokemm4714Maximum hoist pullkN100Maximum feed forcekN50Maximum hoist pull speedm/min12.4Maximum feed speedm/min25.6WinchLine pull(1st layer)kN20Maximum rope speedm/min30Rope diametermm12Rope capacitym50UndercarriageTravelling speedkm/h3.5Max. climbable gradient of the overall unit%36Track shoe widthmm400Over all widthmm2250Overall lengthmm3040Average ground pressurekPa73ClampsNominal sizemm50-255Maximum Clamping forcekN150Maximum breaking torquekN·m30Dimension in transport condition (L × W × H)mm8492×2291×3054Weight of overall unit(standard configuration)kg13500

China Brand Xmz130 Anchor Drilling Rig Crawler Mobile Drilling Rig
