China Brand Pipe Jacking Machine Xdn500 Piping Machinery

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：Online Support
  • Warranty：1 Year
  • Certification：ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Drill Hole Diameter：>300mm
  • Transport Package：Nude Package

Base Info

  • Model NO.：XDN500
  • Trademark：SINOMADA
  • Origin：China
  • Production Capacity：100 Units,Month

Description

Item XDN1000DescriptionUnitParameter valuePipe diameterIDmmΦ1000ODΦ1200Extend diametermmΦ1100Φ1200Outer diameter× lengthmmΦ1220×3600Cutting wheelsMotor powerkW15×2TorquekN.m89Revolutionr/min0-2.8-3.9Roll correction systemForce per cylinderkN480Cylinder numberEA3Steering angle°3Motor powerkW2.2slurry line diametermmΦ100Total powerkW47.2Weightkg6000Jacking cylindersThrustkN1500NumberEA2Strokemm1250×2Charge pump Motor powerkW22Discharge pump Motor powerkW22Injection pump Motor powerkW11
