Yyt26 Hydraulic Rock Drill, Hydraulic Pump Electric Drive

Fuzhou Golden Moral Imp & Exp Co., Ltd.
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：5m
  • Bit Type：Taper Drill Bit

Base Info

  • Model NO.：YYT26
  • Drilling Way：Impactor
  • Transport Package：Sea Shipping
  • Specification：1.4*2.6*1.2M
  • Trademark：GoldenMoral
  • Origin：China
  • HS Code：84671900
  • Production Capacity：100 Unit,Month

Description

Specifications

shank

Water
flushing

Air
flushing

Weight
kg

Length
Overall
mm

Piston
Stroke
mm

Piston Dia
mm

Oil flow
L/ min

22×108

√

√

26

600

24

30

32-35

Hydraulic
Pressure
Mpa

Impact
Energy
J

Impact
Frequency
J

Torque
Nm

Spin
Speed
r/min

Drilling
Hole dia
mm

Water Pressure
Mpa

15-17.5

55-65

55-60

50-55

250-300

φ32-46

0.1-0.3

support leg



Weight
kg

Length
mm

Length
mm(extended)

Feed length
mm

Feed cylinder Dia
mm

12.5

1400

2600

1110

47

Model

Length×width×height
(m)

Weight
kg

Power
kw

Hydraulic pump

1.3×0.7×0.9/1.1×0.6×0.8

450KG/350KG

22KW/15KW
