2021 Water Well Drilling Machine/Drilling Rig
Qingdao Chary Machinery Co., Ltd.- Condition：New
- Motor：Motor
- Drill Hole Diameter：127
- Drill Hole Depth：2500
- Bit Type：Top Drive
- Drilling Way：Rotary
Base Info
- Model NO.：1000
- Type：Automobile Chassis
- Model：1200
- Engine：Cat C18
- Rated Power：571kw
- Rotary Speed：60m,Min
- Max. Drilling Diameter：127
- Max. Drilling Depth：2500m
- Max Extraction Force：1200kn
- Max.Pulling Force：260kn
- Max.Line Speed：30m,Min
- Working Dimension：14680X4970X21400 (L*W*H) mm
- Transportation Dimension：14220X2550X4000 (L*W*H) mm
- Chassis (Drive Mode)：Automobile Chassis
- Weight：55t
- Transport Package：Nude Packing
- Specification：14220X2550X4000
- Trademark：Chary
- Origin：China
- HS Code：8430412100
- Production Capacity：1000,Per Month
Description
1200Project Unit Parameter feeding system Maximum lifting force (kN) 1200 Maximum feeding force (kN) 260 Drilling depth (m) 2500(φ127) Max diameter of work floor (mm) Φ820 Onboard engine Type - CAT C18 Rated power (kW) 571 Top-mounted driving force head Peak torque (N?m) 27500 Speed of rotation (r/min) 0~180 Drift diameter of principal shaft (mm) φ105 Floating stroke of the principal shaft (mm) 100 Stroke (mm) 15240 Fast lifting speed (m/min) 30 Fast lowering speed (m/min) 60 Maximum tilting angle (°) 85 Winching rotary hook Maximum hook load (kN) - Maximum lifting or lowering speed (m/min) - Tool winching Maximum lifting force (kN) 50 Maximum lifting or lowering speed (m/min) 46 Back-off device maximum shackle torque (N?m) 85000 Retaining scope (mm) 0~245 Mud pump Maximum pump discharge (L/min) - Peak pressure (MPa) - Foam pump maximum pump discharge (L/min) 50 Peak pressure (Mpa) 10 Sludge pipe Drift diameter (mm) φ76 Pressure (Mpa) 35 Chassis Driving form - 10×8 Automobile chassis Engine type - ISM11E4 420 Rating of engine (kW) 353 Maximum running speed (km/h) 75 Maximum gradability (%) 42 Working dimension (mm) 14680×4970×21400 Transportation dimension (mm) 14220×2550×4000 Overall weight (t) 55
MULTIPLE SHIPPING WAYS TO SAVE SHIPPING FREIGHT FOR YOU
WHY CHOOSE US?
Experience
10 years experience of production,sales,research and development in the field of special trucks.
Specialization
We can produce according to your demand, the material,the size, the color and the logo is optional for you.
Good quality
Has solid technology, advanced equipments ;Reliant quality and flexible modes of operation also have strict quality control system and passed the iso9001-2008 and the 3c (china compulsory certification),with SGS,BV certifcate as well.
Chassis supply
We have a very good long term cooperation relationship with chassis manufacturer, Such as SINOTRUK, BEIBEN, FAW, FOTON, IVECO, SHACMAN, SHANTUI, CIMC, DONGFENG and so on.
OUR SERVICE
(1) More than 300 workers ,large and advanced production;
(2) Have professional engineer,can offer the best solutions;
(3) With keeping good relation with SINOTRUK, FOTON, ISUZU, DFAC, FOTON, SHACMAN chassis factory.
(4) Build strict QC team to guarantee the quality;
(5) Own good sales team, can offer warm follow-up service.
(6) Spare Parts Supply:
We have our own spear parts departments,have strong production and distribution capability. We can satisfy your demand within 2-7 days. We always do our best to solve the problems, and put our customers' interests in the first place. And We can Supply Spare Parts For Many Brands, Such as SINOTRUK, BEIBEN, FAW, FOTON, IVECO, SHACMAN, SHANTUI, CIMC, DONGFENG and so on.
FAQ
1, How to purchase the trailer truck from your company?
You can choose the model from our website, also you can tell our sales manger your specific requirements and we will recommend the suitable model to you. After confirming the model and price, we can sign the contract.
2,How to ensure product quality?
Firstly,we passed the international quality system certification. Secondly, Made in China Group has conducted field certification for our factory. Finally,You can entrust third party individuals or organizations to inspect our products before delivery.
3, How to visit your factory?
After you arriving at China, you can fly to Qingdao airport. Qingdao airport is located in Qingdao City, Shandong Province. Our driver will meet you at Qingdao airport and take you to our factory by car.
WELCOME TO CONTACT US
If you are interested in any of construction machinery for sale,please feel free to contact me. Also, welcome to China and visit our construction machinery factory for construction machinery price or to discuss more details.
Qingdao Chary Machinery CO., LTD
