• Model NO.：XR150D
• Drilling Way：Rotary
• Max. Drilling Torque：160kn.M
• Drilling Diameter：1500mm
• Base Engine：Mitsubish
• Drilling Depth：42m
• Transport Package：Nude by Roro
• Specification：7550*4200*19040mm
• Origin：China
• HS Code：84305090
• Production Capacity：100 Sets,Month

Overview Product Description



Product Parameters



NO.Name UnitParameters1Max. drilling diametermmÆ13002Max. drilling depthm38(4-section of friction)
(standard)
48(5-section of friction) (optional)
38(4-section of mechanical interlock ) (optional)3Safe operation range(from rotarying centre)mm3150~35504Dimension in working condition(L×W×H)mm7122×4200×172505Dimension in transportation condition(L×W×H)mm12300×3200×30606Overall drilling weight(drilling tools not included)t45.57EngineEngine model CUMINS B5.9-CEngine rated power/rotary speedkW133 /2000r/minMax. Torque of engineN.m553 /1500r/min8Hydrulic systemMax. pressureMpa329Rotary driveMax.output torquekN.m150Rotary speedRotary speedrpm6~2810Pull-Down clinderMax. pull-down piston pushkN120Max. pull-down piston pullkN160Max. pull-down piston strokemm350011Main winchMax. pulling forcekN145Max. wire speedm/min75Wire diametermm2612Auxiliary winchMax. pulling forcekN50Max. wire speedm/min70Wire diametermm1613MastLeft/ right Side°3/3Forwards°514Slewing bearingSlewing bearing angle°36015RuningMax. complete device running speedkm/h3.2Max. complete device grade ability%4016TrackTrack widthmm800Outside width(min-max)mm3200~4200Distance between two wheels longitudinallymm3843Average grouning specific pressureKPa70.5Detailed Photos
