• Model NO.：XY-150
• Type：Drilling Machine
• Usage：Ore,Water Well,Coal
• Transport Package：Wooden Box
• Trademark：GM
• Origin：China
• Production Capacity：1000set,Year

Basic Info.

Model NO. XY-150 Type Drilling Machine Usage Ore/Water Well/Coal Transport Package Wooden Box Trademark GM Origin China Production Capacity 1000set/Year

Product Description

The XY-150 is used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling, etc. With hydro-automatic feeding device, and high drilling efficiency. Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes. Close levers, convenient to operate, safe and reliable operations. Compact in structure. All the drill, water pump and diesel engine installed on one base frame result in space-saving. Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.

Model                                                           XY-150Y
Drilling depth                                                 150m
Maximum open hole diameter                      220mm
End hole caliber                                            75mm
Drill rod caliber                                               50mm
Drilling angle                                                90° ~75°
Drill weight(No include power)                       560kg
