Drilling Rig

Low fuel consumption 36T HDD rig for sale

Jiangsu Goodeng Heavy Machinery Equipment Technology Co., Ltd.
  • After-sales Service:provided
  • Warranty:provided
  • Certification:ISO 9001:2000, ISO 9001:2008
  • Condition:New
  • Drill Hole Diameter:1200 mm
  • Drill Hole Depth:450 m

Base Info

  • Model NO.:GD360-L,LS
  • Bit Type:Drag Bit
  • Drilling Way:Rotary
  • Type:Track
  • Engine Power:153,154 kW
  • Max. Torque:14000 N·m
  • Max. Mud Pump Flow:400 L,Min
  • Transport Package:Nude Packing
  • Specification:7300*2230*2310 mm
  • Trademark:Goodeng
  • Origin:China
  • HS Code:843041
  • Production Capacity:2000,Year

Description

Rig Weight9500/10500 kgDimension(L*W*H)7300*2230*2310(mm)Max. Push&Pull Force380/760 kNMax. Torque14000 N·mMax. Push&Pull Speed36 m/minMax. Rotation Speed135 r/minEngine Power153 kW/154 kWMax. Mud Pump Flow400 L/min Walking Speed2.5-4.0(km/h)Max. Mud Pump Pressure8 MpaEntry Drill Angle13°-23°Max. Climbing Gradient18°Max. Aperture Diameterø1200mm(Soil Depended)Max. Crossing length450m(Soil Depended)
Low fuel consumption 36T HDD rig for saleLow fuel consumption 36T HDD rig for saleLow fuel consumption 36T HDD rig for saleLow fuel consumption 36T HDD rig for saleLow fuel consumption 36T HDD rig for saleLow fuel consumption 36T HDD rig for sale

1. What about the warranty time?

    A:12 months after shipment or 2000 working hours,whichever occurs first.

2. What about the delivery time?

    A:10-20 days after receiving the deposit.

3.What kind terms of payment can be accepted?

    A: On T/T term, 30% down payment is required in advance, and 70% balance shall be before shipment, or against the copy of original BL for old client.

        On L/C term, 100% irrevocable L/C without "soft clause" can be accepted.

4.What logistics ways we can work for shipment?

    A: We can ship machine by sea and road.

 5. What about the after-sales service?

    A: We have office and professional after-sales service team in many countries. After you receiving the new machine, we will provide you one engineering training installation and debugging service for 3-5days. If there are some problems, our after-sales service team will arrive the project site in shortest time.
