• Model NO.：XR360E
• Bit Type：Diamond Bit
• Drilling Way：Rotary
• Type：Crawler
• Dimension：18810×3500×3500
• Operation Weight：90ton
• Colour：Optional
• Engine Model：Cummins
• Transport Package：Nude Packing
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：China
• HS Code：1
• Production Capacity：1000PCS,Month

odel

XR360
EngineModel
CUMMINS QSM11-C400
Rated Power
KW/rpm
298
Rotary DviveMax. output torque
kN·m
360
Rotary speed
r/min
6~25
Max. Drilling DiameterWith casing
mm
2000
Without casing
mm
2500
Winthout 1st mast
mm
3000
Max. Drilling Depth
m
96,81, 65
Pull-Down CylinderMax. pull-down piston push
KN
240
Max. pull-down piston pull
KN
220
Max. pull-down piston stroke
m
6.0
Main WinchMax. pulling force
KN
320
Max. pulling speed
m/min
72
Auxiliary WinchMax. pulling force
KN
100
Max. pulling speed
m/min
≥65
Mast RakeSide/forwards/backwards
±4°/5°/15°
UndercarrigeMax. traveling speed
KM/h
1.5
Max. grade ability
%
40
Min. Clearance
mm
425
Track shoe width
mm
800
Distance between tracks
mm
3500~4800
Hydraulic SystermWorking pressue
Mpa
33
Overall Drilling Weight
t
90
DimensionWorking condition
mm
11000×4800×24586
Transportation condition
mm
18810×3500×3500
1.longer time warranty: one year,
2.package:sea protecting package with film not nude wether by container or not.
3.quality is strong with good steel body frame, brand component, technology is mature.
4.suitable design that the length size of forklift is longer because of the suitable driving space
5.lower price compare the same machines
6.service is satisfied with our after-sales team and engineering team
