Truck Mounted Water Well Deep Bore Hole Drill Rig

Glorytek Industry (Beijing) Co., Ltd.
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：Diesel Engine
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：>200m
  • Bit Type：Diesel Engine

Base Info

  • Model NO.：GL-III
  • Drilling Way：Impactor
  • Type：Truck Mounted Type
  • Keyword：Water Well Drill Rig
  • Hole Diameter：120--1500(mm)
  • Hole Depth：350(M)
  • Run of Rod：3--4(M)
  • Drill Head Lifting Force(Kn)：130
  • Transport Status (L-W-H)：10200*2470*3300(mm)
  • Supporting Form：Hydraulic Unit
  • Rig Mass：12500(Kg)
  • Usage：Water Well
  • Power Type：Diesel
  • Transport Package：Sea Worthy Packing.
  • Specification：9600*2950*7900(mm)
  • Trademark：GLORYTEK
  • Origin：Beijing, China
  • HS Code：8430412100
  • Production Capacity：20 Sets, Month

Description

Performance parameterDrill Head Inside Diameter:φ80 φ120Drill Head lifting Force(kN):130Drill Head Spin Speed:A(Forward:20-33-73,Reverse:13-23-47r/min)B(Forward:41-66-146,Reverse:26-43-94r/min)B(Forward:36-58-127,Reverse:23-37-80r/min)Shape ParametersDimensions:(L-W-H) Working conditions 9600×2950×7900(mm)Transport status:(L-W-H) 10200×2470×3300(mm)Supporting Form:Hydraulic UnitMast Up-Down:Hydraulic UnitRig mass:12500(Kg)Chassis:Dongfeng EQ 1141/JiefangCA1127 (four-wheel drive)Power Unit:Diesel EnginePower:84(kW)Pump:BW600/30 Mud PumpFlow(m³/h):720 513 335Pressure(MP):3 4 5Main Hoist Lifting Force:25(kN)Auxiliary Hoist Lifting Force:8(kN)Notes: Drill head spin speed can be selected, A is normal

 Truck Mounted Water Well Deep Bore Hole Drill RigTruck Mounted Water Well Deep Bore Hole Drill Rig



Related Products

Truck Mounted Water Well Deep Bore Hole Drill Rig


Company Profile

Truck Mounted Water Well Deep Bore Hole Drill Rig



Glorytek Industry (Beijing) Co., Ltd. is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for more than 20 years. We are supported and assisted by highly experienced R&D team and enginners that enable us to complete all the assigned projects successfully as per clients' requirements.

Our factory covers an area of 250,000 square meters, construction area is about 150,000 square meters, having machining machinery, CNC processing center, friction welding machine, testing equipments etc. over 200 sets and more than 600 employees.

Our products have been exported more than 60 countries, including Australia, Russia, Soutn Africa, Zimbabwe, Malaysia, Indonesia, South Korea, France, Sweden, USA, Canada, Haiti etc.

Truck Mounted Water Well Deep Bore Hole Drill Rig
Truck Mounted Water Well Deep Bore Hole Drill Rig

Truck Mounted Water Well Deep Bore Hole Drill Rig


FAQ

Q: How can we choose a suitable water well drill rig?
A: We normally recommend a suitable model according to drilling depth, drilling hole dia. and layer condition on site.


Q: Are you a factory or a trading company ?
A: We are an integrated corporation specialized in manufacturing and exporting.


Q: What is your payment terms?
A: We can accept T/T,L/C.

Q:.What is your MOQ? How long is the delivery time?
A: Our MOQ is 1 sets. Normally for drill rig, the delivery time is about 25-30 days after receiving payment, the drilling tools would be about 15 days.

Q:. How long is the warranty?
A: The guarantee period for mainframe is one year (excluding the quick wear parts).

Q: Can we print my Logo on the products?
A: Yes, we can. We support OEM .
