15 Ton HDD Small Portable Horizontal Directional Drilling Machines
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- After-sales Service：7*24 Online Service
- Condition：New
- Drill Hole Diameter：>300mm
- Drill Hole Depth：10-30m
- Bit Type：Diamond Bit
- Drilling Way：Rotary
Base Info
- Model NO.：DFHD-15
- Type：Rotary Drilling Rig
- Guide Hole Dia.：80mm
- Drilling Angle：8-20 Degree
- Feeding Stroke：3500mm
- Power：85kw
- Walking Speed：2.5km,H
- Rotary Torque：4200n.M
- Mud Pump：Bw-150A
- Reamer：179, 259, 313, 365, 417
- Color：Yellow
- Quality：China Standard
- Usage：Ore
- Power Type：Diesel
- Transport Package：Naked Package for Main Machine
- Specification：BV,SGS
- Trademark：DEFY
- Origin：China
- Production Capacity：50 Set Per Month
Description
Pulling Force(KN) DFHD-15 85KW (2200r/min) 75 150 DFHD-20 110KW (2300r/min) 200 200 DFHD-28 132KW (2300r/min) 280 280 DFHD-32 145KW(2300r/min) 320 320 DFHD-40 175KW(2300r/min) 400 400 DFHD-60 225KW (2200r/min) 620 620 DFHD-120 338KW (1900r/min) 1220 1220 DFHD-245 450KW*2 sets 2450 2450 DFHD-400 552KW*2 sets 4000 4000 DFHD-550 784KW*2 sets 5500 5500 DFHD-750 960KW*2 sets 7500 7500 Machine deliver to Cambodia Contact Info: Debbie Liu
Our service
Delivery time : depends on the quantity, usually it is 10 working days.
Quality control : we have QC department, before shipping, goods will be strictly checked.
Tech support :
- 24 hours * 7 days online pre & after sale service ;
- Factory site training or engineers go to overseas to train the workers ;
- Manual and DVD operation video.
