Small Trailer Mounted Diamond Core Drilling Machine

Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：200-250mm
  • Drill Hole Depth：100-150m
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary

Base Info

  • Model NO.：XY-130
  • Power Supply：Diesel Engine 18HP or 11kw Electrical Motor
  • Drilling Hole Diameter：300~75mm
  • Max. Drilling Depth：130m
  • Drill Pipe Diameter：50mm
  • Capability：Soil, Gravel, Pebble, Hard Rock etc.
  • Export to：Africa, South America, Southest Asia and So on
  • Mining Object：Metallic and Non-Metallic Ore Excavator
  • Usage：Ore, Blasthole, Water Well, Coal
  • Power Type：Diesel
  • Type：Core Drilling Rig
  • Transport Package：Standard Export Packing
  • Specification：BV&SGS&ISO
  • Trademark：DEFY
  • Origin：China
  • Production Capacity：200 Sets Per Month

Description

Specifications1.Overall parametersDrilling depth130mMaximum open hole caliber300mmEnd hole caliber75mmDiameter of drill rod50mmDrilling angle90~75 °2. Vertical Spindle Rotating speed140, 295, 470,790,1010 r/minFeeding stroke450mm3.Hoist Max. single line hoisting capacity1600KgDiameter of wire rope12mmRotary speed of winding drum35mVolume of winding drum245mmHug floodgate belt width70mm4.Mud pump TypeHorizontal single urn twin-actionRate of flow95/77L/minMAX. pressure1.2MPaWorking pressure0.7MPa5.Power Diesel engine ZS111518HP, 2000r/minElectrical motor Y-160-411KW, 1460r/min
Small Trailer Mounted Diamond Core Drilling Machine
 Disassemble drill tower;
Small in size.XY -1307 5~ 30 0mm1 3 0m2-wheel trailerXY-1507 5~ 40 0mm150m2-wheel trailerXY -1807 5~ 40 0mm1 8 0m2-wheel trailerXY -2007 5~ 40 0mm200m2-wheel trailerXY-200F7 5~ 40 0mm200m4-wheel trailerIntegrative drill tower;
Easy to transport.XY-200C7 5~ 40 0mm200mcrawlerXY-600F7 5~ 50 0mm6 00m6-wheel trailer
