• Model NO.：BZ-30
• Type：Portable
• Power Type：Kohler Xt Series, Gasoline Engine
• Rig Weight：54kg
• Stability：Good
• Transport Package：in Plywood Case
• Specification：30
• Trademark：csmiracleland
• Origin：Changsha, China
• HS Code：8430691900
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. BZ-30 Type Portable Power Type Kohler Xt Series, Gasoline Engine Rig Weight 54kg Stability Good Transport Package in Plywood Case Specification 30 Trademark csmiracleland Origin Changsha, China HS Code 8430691900 Production Capacity 20 Sets/Month

Product Description

Compact structure, can be disassembled, small volume, light weight, easy to carry; Gasoline engine has high horsepower, drilling depth is guaranteed; With drill stand, which is more convenient and safe for outside work.

Product Application:

The BZ-30 vertical backpacking drill is a portable rock core drill which can be disassembled and carried away. It is mainly used for mineral exploration, geochemical exploration, shallow sampling, vein exploration, geological research, engineering exploration, oil field exploration, water conservancy engineering investigation, highway engineering investigation, tunnel lining, invert inspection, etc.




The technical parameters of BZ-30 portable backpacking drill rig:


Model	BZ-30
Drilling depth	30m
Drill rod diameter	32mm
Drilling diameter	32-108mm
Adaptation geological	soil, loose cover, all kinds of rock
Engine type	KOHLER XT series, gasoline engine
Oil consumption	0.35L/min
Oil tank volume	1400ml
Drive mode	Gear transmission
Variable speed proportion	7:1
Coring mode	rotary
Rig rated speed	540r/min
Power	7.75hp
Drill rod length	800mm
Drill bit diameter	φ32, φ46, φ60 φ108mm
Weight (including holder  )	54kg
Dimension (LxWxH)	550x450x420mm
