• Model NO.：XY-600F
• Drilling Way：Rotary
• Transport Package：Wooden Package
• Specification：SGS BV
• Trademark：DEFY
• Origin：China
• HS Code：84304900
• Production Capacity：50 Set Per Month

1. Main Parameters
 Max. Drilling Depth
 600m
 Diameter of drill pipe
 Φ42,Φ50,Φ60,Φ76
 Angle of vertical spindle
 90°~65°
 2. Drilling capability
 Φ75mm drill diameter
 600m depth
 Φ108mm drill diameter
 500m depth
 Φ127mm drill diameter
 400m depth
 Φ159mm drill diameter
 300m depth
 Φ219mm drill diameter
 210m depth
 Φ273mm drill diameter
 150m depth
 Φ500mm drill diameter
 80m depth
 3. Mud pump(as per your choice)
 Horizontal triplex mud pump
 BW-200II
 Displacement
 200L/min
 Working pressure
 50kg/cm² @ 5MPa
 Diameter of water inlet hose
 65mm
 Diameter of water outlet hose
 38mm
 4. Power supply
 Diesel engine
 Model 4100,38kw(50PS)
 Electrical motor
 Y180M-4B35,22kw
 5. Weight and Dimension of main drilling rig
 Weight
 2880kg
 Dimension
 3700×1850×3200mm
