2022 Hot Sale 100m Deep Crawler Mounted Ground Water Hole Drilling Machines
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- Warranty：12 Months, 1 Year
- Certification：ISO 9001:2000, ISO 9001:2008
- Condition：New
- Motor：Diesel Engine
- Drill Hole Diameter：105-150
- Drill Hole Depth：100
Base Info
- Model NO.：DFQ-100
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Type：Rotary Drilling Rig
- Max Depth：100m
- Drilling Caliber：105-150mm
- Power(W)：24kw
- Dimension(L*W*H)：3200*1770*2050 mm
- Application：Hard Rock, Water Well Drilling Rig
- Control System：Hydraulic Control System
- Worker Train：Free Train
- Usage：Ore, Water Well, Coal
- Power Type：Diesel
- Transport Package：Container or Wooden Box
- Specification：CE BV ISO SGS
- Trademark：DEFY
- Origin：Zhengzhou, Henan Province
- Production Capacity：50 Sets
Description
DFQ-100 100m deep Crawler mounted ground water hole drilling machines No. Item DFQ-100 1 Drilling caliber Φ105-150 mm 2 Max. drilling depth 100m 3 Diameter of drill pipe Φ60, Φ63.5 4 Work pressure 1.05-2.0 MPa 5 Gas consumption 15-18 m³/min 6 Impacter DHD340350 7 Apply to rock hardness f=6-12 8 Power 24Kw/2300rpm 9 Propulsion 5.0tonf 10 Lifting force 8.5tonf 11 Speed of spindle Fast 135 rpm
Slow 91 rpm 12 Rotary torque 1050N.m
Working Site:
Company Information:
ZhengZhou Defy 12 years professional exporting experience, realiable drilling machine manufacturer since 1970S.
Defy offer water well drilling machines drilling depth from 100m, 200m, 400m, 600m, 800m and 1500m. with 75-1500mm diameter. geotechnical core drilling machine from 0-3000m depth.
Spindle rotary type drilling machine, ground water hole drilling machines, pneumatic air operated drilling machine, trailer, crawler, truck mounted drilling machine for your choices.
Contact Info:
If you have interest in our ground hole drilling machines, please feel free to contact me at any time. or just send me an inquiry, write your drilling requirements, i will serve you very well.
