Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig

TYSIM Piling Equipment Co., Ltd.
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：50-70m
  • Drilling Way：Rotary
  • Type：Crawler

Base Info

  • Model NO.：KR150A
  • Torque：150 Kn.M
  • Max. Diameter：1500 mm
  • Max. Drilling Depth：52
  • Max. Crowd Pressure：100 Kn
  • Max. Crowd Pull：150 Kn
  • Main Winch Line Pull：110 Kn
  • Operating Height：16175 mm
  • Operating Width：3390mm
  • Transport Package：Bulk Pack
  • Specification：40 t
  • Trademark：tysim
  • Origin：Jiangsu, China
  • HS Code：8430412900
  • Production Capacity：30pieces,Month

Description

Basic Info.

Model NO. KR150A Torque 150 Kn.M Max. Diameter 1500 mm Max. Drilling Depth 52 Max. Crowd Pressure 100 Kn Max. Crowd Pull 150 Kn Main Winch Line Pull 110 Kn Operating Height 16175 mm Operating Width 3390mm Transport Package Bulk Pack Specification 40 t Trademark tysim Origin Jiangsu, China HS Code 8430412900 Production Capacity 30pieces/Month

Product Description

Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig
Technical Specification
TypeKR150A
Torque150KN.m
Max. diameter11500mm
Max. drilling depth52 m
Speed of rotation6~30 rpm
Max. crowd pressure100 kN
Max. crowd pull150 kN
Main winch line pull110 kN
Main winch line speed78 m/min
Auxiliary winch line pull60 kN
Auxiliary winch line speed60 m/min
Stroke(crowd system)3800 mm
Mast inclination(lateral)±3°
Mast inclination(forward)5°
Max. operating pressure34.3 MPa
Pilot pressure3.9 MPa
Travel speed3 km/h
Traction force229 kN
Operating height16175m
Operating width3390
Transport height3655 mm
Transport width3390 mm
Transport length14765mm
Overall weight40 t
Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig
Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig
Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling RigSales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig



Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig

Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling RigSales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig
Sales Auger Bore Pile Foundation Machine Kr150A Well Hydraulic Rotary Drilling Rig
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is an year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
