• Model NO.：KR125A
• Torque：125 Kn.M
• Max. Diameter：1300 mm
• Max. Drilling Depth：37 M(Lock), 43 M(Friction Kelly Bar)
• Max. Crowd Pressure：100 Kn
• Max. Crowd Pull：150 Kn
• Main Winch Line Pull：110 Kn
• Operating Height：14980 mm
• Operating Width：3000mm
• Transport Package：Bulk Pack
• Specification：35 t
• Trademark：tysim
• Origin：Jiangsu, China
• HS Code：8430412900
• Production Capacity：30pieces,Month

Basic Info.

Model NO. KR125A Torque 125 Kn.M Max. Diameter 1300 mm Max. Drilling Depth 37 M(Lock)/ 43 M(Friction Kelly Bar) Max. Crowd Pressure 100 Kn Max. Crowd Pull 150 Kn Main Winch Line Pull 110 Kn Operating Height 14980 mm Operating Width 3000mm Transport Package Bulk Pack Specification 35 t Trademark tysim Origin Jiangsu, China HS Code 8430412900 Production Capacity 30pieces/Month

Product Description

Technical Specification

Type	KR125A
Torque	125 KN.m
Max. diameter	1300 mm
Max. drilling depth	37 m(Lock)/ 43 m(Friction kelly bar)
Speed of rotation	8~30 rpm
Max. crowd pressure	100 kN
Max. crowd pull	150 kN
Main winch line pull	110 kN
Main winch line speed	78 m/min
Auxiliary winch line pull	60 kN
Auxiliary winch line speed	60 m/min
Stroke(crowd system)	3200 mm
Mast inclination(lateral)	±3°
Mast inclination(forward)	5°
Max. operating pressure	34.3 MPa
Pilot pressure	3.9 MPa
Travel speed	3 km/h
Traction force	220 kN
Operating height	14980 mm
Operating width	3000mm
Transport height	3580 mm
Transport width	3000 mm
Transport length	13830mm
Overall weight	35 t

Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is an year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
