350m CE/ISO Crawler Pneumatic Borehole Mining Core DTH Water Well Drill/Drilling Rigs Machine for Rock

Speedmade Industries Co., Ltd.

After-sales Service：Video Technical Support
Warranty：1 Year
Certification：ISO 9001:2000
Condition：New
Motor：AC Motor
Drill Hole Diameter：140-325 mm

Base Info

Drill Hole Depth：350m
Bit Type：Multi-Function
Drilling Way：DTH
Type：Core Drilling Rig
Condetion：New
Application：Water Well, Water Well
Video Outgoing-Inspection：Provided
Place of Origin：China
MOQ：1
Power：100-120kw Diesel Engine
Weight：20340kg
Features：Multi-Drilling Process, Reliable Quality
Chassis：Sinotruck,Dongfeng Truck
Drilling Pipe：73,76,89,114
The Capacity of Main Winch：18 Ton
Max Feeding Capacity：80jkn
Transport Package：Exported Package
Specification：6800*1900*2600MM
Trademark：speedmade
Origin：China
HS Code：82071990
Production Capacity：10000piece,Pieces Per Year

Description

TECHNICAL SPECIFICATIONSItemFY350 crawler Fast feeding speed33 m/minThe engine brandYuchai 4cylinderWidth of loading2.7 mEquipped capacitor (Kw)92 kWHoisting force of winch2 TThe hole diameter(mm)140-325 mmUsing air pressure (Mpa)1.7-3.4 MpaDrilling depth (m)350mSwing torque (N.m)6200-8500 N.mDrill pipe diameter(mm)φ89mm φ102mmAir consumption 17-36 m³/minDrill pipe length(m)1.5m 2.0m 3.0m 6.0mSwing speed(rpm)66-135rpmRig lifting force22 TEquipped with hammerMedium and high wind pressure seriesOne-time advance length(m)6.6 mpenetration efficiency15-35 m/hRapid rise speed 18 m/minHigh leg stroke1.4 mWalking speed(km/h)2.5 km/hThe weight (T)8.6 TClimbing angles(Max.)30°Dimensions(mm)6000*2000*2550 mm

350m CE/ISO Crawler Pneumatic Borehole Mining Core DTH Water Well Drill/Drilling Rigs Machine for Rock

WHY CHOOSE SPEEDMADE INDUSTRIES Co.,Ltd?

1.Our propose is to supply the most suitable borehole drilling machine to users.
You can get a full range of product selection advice and product customization without paying any fees.

2.We have two special groups of design teams. One team of after-sales engineers with more than 30 years of construction experience at home and abroad, other team of designers who graduated from well-known universities and have rich work experience. We will combine a wealth of practical construction experience and the most advanced professional theoretical knowledge to meet your various demands.

3.We are not only familiar with borehole drilling rig, but also familiar with the human environment, construction environment and strata in the construction field at home and abroad. Provide you with the greatest technical support, save costs and create the greatest value with you. Yes, choosing us is your best decision.

4. Support overseas train and maintain. We do ten days overseas train for free,after you buy our machine.

5. One year Warranty. Speedmade knows the various needs of the water well service companies and operators worldwide.
Customers who buy rigs from us can benefit from great saving thus boost their bottom line.
