Factory Price Fast Moving Speed Xj350 Mobile Workover Rig
Shandong Beyond Petroleum Equipment Co., Ltd.- Warranty：1 Year
- Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
Base Info
- Model NO.：XJ350
- Condition：New
- Motor：AC Motor
- Drill Hole Diameter：>300mm
- Drill Hole Depth：>300m
- Bit Type：Cone Bit
- Drilling Way：Rotary
- Specification：18.5*2.9*4.2m
- Trademark：Beyond
- Origin：China
- HS Code：8431431000
- Production Capacity：1000pecies,Year
- Package size per unit product：1850.00cm * 290.00cm * 420.00cm
- Gross weight per unit product：51000.000kg
Description
XJ350 Workover Rig (Overhaul)XJ350 Workover Rig (Servicing) Workover Depth 3,200m (10,500ft, 2-7/8″DP)2,500m (8,200ft, 3-1/2″DP) Servicing Depth 4,000m (13,120ft, 2-7/8″EUE Tubing) Rated Hook Load 600kN (134,900 lbf) Max. Hook Load 900kN (202,330 lbf) Traveling System 3×4 {Φ26mm (1'') Wireline} Hook Hoisting Speed 0.25~1.4m/s (0.82~4.6ft/s) Overall Dimensions(l×w×h) 18.5×2.9×4.2m60.7ft×9.5ft×13.8 ft 18.5×2.85×4.2m60.7×9.4×13.8ft Total Weight 51,000kg (112,440 lb) 49,500kg (109,130 lb) Max.Travel Speed 45km/h (28mil/h) Carrier Self-propeller 10×8 Engine Model andRated Power Caterpillar C9260kW (350hp)/2100rpm Detroit S6063298kW (400hp)/2100rpm Transmission Allison 4700 OFS Allison M5610s Derrick Height 31.7m (104ft) Max. Static Load 900kN (202,330 lbf) Racking Board Capacity 4,000m (13,120 ft, 2-7/8″EUE Tubing) Racking board Height 16.8m (55 ft) Drawwork Rated Power 224kW (300hp, Double drum) 238kW (320hp) Main Drum Φ406×890mm (Φ16″×35'') Φ429×965mm (Φ16.9″×38'') Max. Faster Line Pull 180kN (40,470 lbf ) Sanding Drum Φ965×264mm (Φ38″×10.4'') Air Assist Brake System KOBELT Disc4-7-35″ Caliper 5026-CM KOBELT Disc4-7-48″ Caliper 5026-CM Drill Floor (l×w×h) 4.2×4.2×3.7m (13.8×13.8×12.1 ft) Swivel Model and Max. Load SL90 900kN (202,330 lbf) ZP125 Rotary Table
1. The mast is available in 31m, 29m or 25m.
2. The chassis has good cross-country performance. The single drum work-over rig is with 8×8 full-driven chassis. The double drum work-over rig is with 10×8 chassis.
3. Workover unit is with the characteristic of reasonable arrangement, compact structure, good transportation performance and easy for field installation and maintenance, etc.
4. The drawworks auxiliary brake is water brake. Pneumatic tong brake and pneumatic water cooling disc brake are optional.
5. Substructure and simple working platform are optional.
Certifications
Company Profile
Shandong Beyond Petroleum Equipment Co., Ltd, was established in year 2016 and certified by ISO9001. Its main business scope is to supply drilling equipment and spares for overseas customers from different sectors, like petroleum, water well, construction and HDD.Beyond products cover but not limited to: oil drilling & workover rig, water well drilling rig, pile drilling rig, horizontal directional drilling rig, mud pump and spares, solid control system & equipment, and other different drilling materials.Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. We can customize the product supply as per your on-site conditions, and we can offer overseas after-sale services with our strong technical support.
Packaging & Shipping
Max. Load 900 kN (202, 330 lbf
Max. Open Dia. 292mm (11.5")
Features:
1. The mast is available in 31m, 29m or 25m.
2. The chassis has good cross-country performance. The single drum work-over rig is with 8×8 full-driven chassis. The double drum work-over rig is with 10×8 chassis.
3. Workover unit is with the characteristic of reasonable arrangement, compact structure, good transportation performance and easy for field installation and maintenance, etc.
4. The drawworks auxiliary brake is water brake. Pneumatic tong brake and pneumatic water cooling disc brake are optional.
5. Substructure and simple working platform are optional.
