• Model NO.：XY-3
• Type：Slide Base
• Power：30kw
• Rotational Speed (R/Min)：1470
• Spindle Dia. (mm)：76
• Angle of Rotation：0 to 360°
• Lifting Capacity (Kn)：60 (Rated), 75 (Max.)
• Pressing Capacity (Kn)：45 (Rated), 55 (Max.)
• Stroke (mm)：600
• Oil Cylinder Stroke (mm)：460
• Dimension (L × W × H) (mm)：2490X920 X1880
• Net Weight (Kgs)：1300
• Transport Package：Seaworthy Packing
• Specification：for B, N, H, P drilling hole diameters
• Trademark：BOHWA
• Origin：China
• HS Code：84304900
• Production Capacity：20 Set,Sets Per Month

Drill TypeXY-3Engine/
MotorNameElectric MotorDiesel EngineTypeY200L-4B35YC4D60-D21Power30KW40KWRotational Speed (r/min)14701500Drilling CapacityDrilling Rod Dia. (mm)Drilling Depth (m)Final Hole Dia. (mm)Φ55.5  Wireline Core Drilling Pipe60059Φ71 Wireline Core Drilling Pipe45076Φ54  Common Drilling Stem50059Φ60 PQ Common Drilling Stem40076RotatorSpindle Rotational Speed (r/min)Clockwise: 33, 65, 109, 165, 215, 302, 507, 766, 1002 Anticlockwise: 36, 167Spindle Dia. (mm)76Angle of Rotation0 to 360°Feed SystemModelDouble oil tankLifting Capacity (KN)60 (rated), 75 (max.)Pressing Capacity (KN)45 (rated), 55 (max.)Stroke (mm)600WinchModelPlanetary typeThree-layer Single-rope Hoist Capacity (KN)Max. 32Three-layer Single-rope Hoist Speed (m/s)0.72, 1.2, 1.82, 2.38Drum Diameter (mm)220Wire Rope Diameter (mm)14Wire Rope Capacity (m)55Hydraulic SystemOil Pump ModelCBTLFT-416/E410-ALH6Oil Pump Displacement (ml/r)16+10System Pressure (MPa)8 (rated), 10 (max.)Oil Cylinder Stroke (mm)460Dimension (L × W × H) (mm)2490 × 920 × 1880 (Electromotor) 2615 × 920 × 1880 (Diesel engine)Net Weight (kgs)1300
