• Model NO.：XR160
• Type：Crawler
• Excellent After-Sale Service and Spare P：Excellent After-Sale Service and Spare Parts
• Power Source：Diesel
• Usage：Construction
• Transport Package：Suitable Package for Shipment
• Specification：ISO
• Trademark：EON
• Origin：Xuzhou, China
• HS Code：8701200000
• Production Capacity：1, 000units,Month

Engine
 Model

 CUMMINS 6CTA8.3-C240
 Rated Power
 KW/rpm
 177
 Rotary Dvive
 Max. output torque
 kN@m
 160
 Rotary speed
 r/min
 826
 Max. Drilling Diameter
 With casing
 mm
 1200
 Without casing
 mm
 1600
 Max. Drilling Depth
 m
 54, 42
 Pull-Down Cylinder
 Max. pull-down piston push
 KN
 160
 Max. pull-down piston pull
 KN
 180
 Max. pull-down piston stroke
 m
 5.0
 Main Winch
 Max. pulling force
 KN
 150
 Max. pulling speed
 m/min
 80
 Auxiliary Winch
 Max. pulling force
 KN
 75
 Max. pulling speed
 m/min
 ≥ 70
 Mast Rake
 Side/forwards/backwards

 ± 5° /5° /15°
 Undercarrige
 Max. traveling speed
 KM/h
 2.0
 Max. grade ability
 %
 40
 Min. Clearance
 mm
 460
 Track shoe width
 mm
 600
 Distance between tracks
 mm
 23403340
 Hydraulic Systerm
 Working pressue
 Mpa
 30
 Overall Drilling Weight
 t
 56
 Dimension
 Working condition
 mm
 8105× 3940× 18230
 Transportation condition
 mm
 13645× 2940× 3380
