Hf054 40m Separated DTH Drilling Rig

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Drill Hole Diameter：Ф114-219mm
  • Drill Hole Depth：40m
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary

Base Info

  • Model NO.：HF054
  • Type：Crawler
  • Drilling Diameter：114-219mm
  • Drilling Depth：40m
  • Working Air Pressure：1.2-2.4MPa
  • Air Consumption：11 -25mm³,Min
  • The Biggest Pipe-Rod Changing Length：3m
  • Propulsion Power：6000kgf
  • Moving Speed：2km,H
  • Gradeability：24°
  • Power：30-70kw
  • Weight：6200kg
  • Transport Package：Standard Export Packing
  • Specification：CE, ISO
  • Trademark：HANFA
  • Origin：Zhengzhou City, China
  • HS Code：843041
  • Production Capacity：30sets,Month

Description

Overview Product Description

Product Parameters



Drilling diameter



follow-pipe :Ф114-Ф219mm

Down-hole :Ф105-Ф200mm



Drilling depth

follow-pipe :40m

Down-hole :200m

Working air pressure

1.2-2.4Mpa

Air consumption

11 -25mm³/min

The biggest pipe-rod changing length

3m

Propulsion power

6000kgf

Moving speed

2km/h

Gradeability

24°



Power

internal combustion 70kw

Electric           30kw

Outer size(L*W*H)

(transportation state)6900*2200*2200

Weight

6200kg

Dust removol

Wet type(optional)

Company Profile

Hf054 40m Separated DTH Drilling RigHf054 40m Separated DTH Drilling RigHf054 40m Separated DTH Drilling RigFAQ

1.Are you trading company or manufacturer?

We are professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.

2.Are your products qualified?
Yes, our products all have gained ISO certificate,and we have specialized quality inspection department for checking every machine before leaving our factory.

3.How about your machine quality?
All of our machines hold the ISO, QC and TUV certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.

4.Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.

5.What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.

6.How long can you deliver the machine?
Generally, we can deliver the machine in 7 days.
