Truck Mounted Drilling Rig Xj350 for Workover with 3200m

Shandong Beyond Petroleum Equipment Co., Ltd.
  • After-sales Service：Online, Engineer
  • Warranty：One Year
  • Certification：CE
  • Condition：New
  • Motor：SCR
  • Drill Hole Diameter：>300mm

Base Info

  • Model NO.：XJ350
  • Drill Hole Depth：>300m
  • Bit Type：Cone Bit
  • Drilling Way：Rotary
  • Workover Depth：3,200m (10,500FT, 2-7,8″dp)
  • Servicing Depth：4,000m (13,120FT, 2-7,8″eue Tubing)
  • Rated Hook Load：600kn (134,900 Lbf)
  • Max. Hook Load：900kn (202,330 Lbf)
  • Hook Hoisting Speed：0.25~1.4m,S (0.82~4.6FT,S)
  • Transport Package：Export Packing
  • Trademark：BEYOND
  • Origin：China
  • HS Code：8431431000
  • Production Capacity：1000sets,Year

Description

3,200m (10,500ft, 2-7/8″DP)2,500m (8,200ft, 3-1/2″DP) Servicing Depth4,000m (13,120ft, 2-7/8″EUE Tubing)Rated Hook Load600kN (134,900 lbf)Max. Hook Load900kN (202,330 lbf)Traveling System3×4 {Φ26mm (1'') Wireline}Hook Hoisting Speed0.25~1.4m/s (0.82~4.6ft/s)Overall Dimensions(l×w×h)18.5×2.9×4.2m60.7ft×9.5ft×13.8 ft18.5×2.85×4.2m60.7×9.4×13.8ftTotal Weight51,000kg (112,440 lb)49,500kg (109,130 lb)Max.Travel Speed45km/h (28mil/h)CarrierSelf-propeller 10×8Engine Model andRated PowerC9260kW (350hp)/2100rpmS6063298kW (400hp)/2100rpmTransmissionAllison 4700 OFSAllison M5610sHeight31.7m (104ft)Max. Static Load900kN (202,330 lbf)Racking Board Capacity4,000m (13,120 ft, 2-7/8″EUE Tubing)Racking board Height16.8m (55 ft)Drawwork Rated Power224kW (300hp, Double drum)238kW (320hp)Main DrumΦ406×890mm (Φ16″×35'')Φ429×965mm (Φ16.9″×38'')Max. Faster Line Pull180kN (40,470 lbf )Sanding DrumΦ965×264mm (Φ38″×10.4'')Air Assist Brake SystemKOBELT Disc4-7-35″ Caliper 5026-CMKOBELT Disc4-7-48″ Caliper 5026-CMDrill Floor (l×w×h)4.2×4.2×3.7m (13.8×13.8×12.1 ft) Swivel Model and Max. LoadSL90  900kN (202,330 lbf) ZP125 Rotary Table

Max. Load 900 kN (202, 330 lbf

Max. Open Dia. 292mm (11.5")
