Horizontal Directional Drilling Push-Pull System Xz180 8.5tons

Newindu Construction Engineering (Shanghai) Co., Ltd.
  • After-sales Service：Online Service
  • Warranty：One Warranty
  • Certification：CE
  • Condition：New
  • Drill Hole Diameter：73mm, 73mm
  • Drill Hole Depth：Max.600m

Base Info

  • Model NO.：XZ180
  • Bit Type：Cone Bit
  • Drilling Way：Rotary
  • Type：Crawler
  • Rated Power：97kw
  • Dimension：6400X2270X2340mm
  • Max Thrust-Pull Force：180kn
  • Transport Package：LCL, 20gp
  • Specification：10500kg
  • Trademark：CHIAN TOP BRAND
  • Origin：China
  • HS Code：8427209000
  • Production Capacity：100

Description

Model

XZ180

Engine

top brand

Rated power

97kW

Push-pull

Motor

Max.pullback/thrusting

180/180kN

Spindle torque(max)

6000N.m

Spindle speed

0~140r/min

Travelling speed of power head

20m/min

Pipe length(single)

3m

Pipe diameter

Φ60mm

Entry angle

10-22°

Mud flow rate(max)

250L/min

Mud pressure(max)

80bar

Overall weight

8500kg

Dimension(L*W*H)

6400x2270x2340mm
