New Portable 480kn Horizontal Directional Drill Rig Xz450
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Warranty：One Warranty
- Certification：CE
- Condition：New
- Drill Hole Diameter：73mm
- Drill Hole Depth：Max.500m
Base Info
- Model NO.：XZ450
- Bit Type：Cone Bit
- Drilling Way：Rotary
- Type：Crawler
- Rated Power：97kw
- Dimension：8800X2200X2610mm
- Max Thrust-Pull Force：480kn
- Transport Package：LCL, 20gp
- Specification：13300kg
- Trademark：CHIAN TOP BRAND
- Origin：China
- HS Code：8427209000
- Production Capacity：100
Description
Model
XZ450
Engine
TOP BRAND
Rated power
194/2200
Push-pull
Rack and pinion
Max.pullback/thrusting
480kN
Spindle torque(max)
23500N.m
Spindle speed
0~135r/min
Travelling speed of power head
38m/min
Backreaming diameter
Φ800mm
Pipe length(single)
3m
Pipe diameter
Φ89mm
Entry angle
10-20°
Mud flow ratw(max)
320L/min
Mud pressure(max)
80bar
Overall weight
13300kg
Dimension(LxWxH)
8800x2200x2610mm
