Crawler Based Diamond Core Drill Rig for Geological Exploration Drilling

Qingdao Bohwa Machinery Corporation
  • Certification：ISO 9001:2000
  • Condition：New
  • Motor：Diesel
  • Drill Hole Diameter：100-150mm
  • Drill Hole Depth：>200m
  • Bit Type：Diamond Bit

Base Info

  • Model NO.：BH-XY-TL
  • Drilling Way：Rotary
  • Drilling Depth：600-1000m
  • Drill Angle：45-90°
  • Spindle Speed：101-1191rpm
  • Max.Spindle Torque：2640-3800n.M
  • Spindle Feeding Stroke：600mm
  • Spindle Hold Diameter：68-92mm
  • Max.Lifting Capacity of Spindl：80-120kn
  • Max.Pressuring Force of Spindle：60-90kn
  • Steel Wire Diameter：16-17.5mm
  • Winding Drum Capacity：90-110m
  • Max. Hoisting Force：30-45kn
  • Drill-Tower Height：10m
  • Auxiliary Hoister：12kn
  • Max. Load of Mast：100kn
  • Transport Package：Nude Package
  • Specification：Power: 74-97kw
  • Trademark：BOHWA
  • Origin：China
  • HS Code：8430412900
  • Production Capacity：30 Set,Sets Per Month

Description

Weight9.3t9.6t10tCrawler Based Diamond Core Drill Rig for Geological Exploration DrillingCrawler Based Diamond Core Drill Rig for Geological Exploration DrillingCrawler Based Diamond Core Drill Rig for Geological Exploration DrillingCrawler Based Diamond Core Drill Rig for Geological Exploration DrillingCrawler Based Diamond Core Drill Rig for Geological Exploration DrillingCrawler Based Diamond Core Drill Rig for Geological Exploration Drilling
