• Model NO.：KR150
• Torque：150 Kn.M
• Max. Diameter：1500 mm
• Max. Drilling Depth：52
• Max. Crowd Pressure：100 Kn
• Max. Crowd Pull：150 Kn
• Main Winch Line Pull：110 Kn
• Operating Height：16175 mm
• Operating Width：3390mm
• Transport Package：Bulk Pack
• Specification：40 t
• Trademark：tysim
• Origin：Jiangsu, China
• HS Code：8431499900
• Production Capacity：30pieces,Month

Basic Info.

Model NO. KR150 Torque 150 Kn.M Max. Diameter 1500 mm Max. Drilling Depth 52 Max. Crowd Pressure 100 Kn Max. Crowd Pull 150 Kn Main Winch Line Pull 110 Kn Operating Height 16175 mm Operating Width 3390mm Transport Package Bulk Pack Specification 40 t Trademark tysim Origin Jiangsu, China HS Code 8431499900 Production Capacity 30pieces/Month

Product Description

Technical Specification

Type	KR150A
Torque	150KN.m
Max. diameter	11500mm
Max. drilling depth	52 m
Speed of rotation	6~30 rpm
Max. crowd pressure	100 kN
Max. crowd pull	150 kN
Main winch line pull	110 kN
Main winch line speed	78 m/min
Auxiliary winch line pull	60 kN
Auxiliary winch line speed	60 m/min
Stroke(crowd system)	3800 mm
Mast inclination(lateral)	±3°
Mast inclination(forward)	5°
Max. operating pressure	34.3 MPa
Pilot pressure	3.9 MPa
Travel speed	3 km/h
Traction force	229 kN
Operating height	16175m
Operating width	3390
Transport height	3655 mm
Transport width	3390 mm
Transport length	14765mm
Overall weight	40 t

Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is 1 year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
