Used Water Well Drilling Machine for Sale

Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
  • Condition：New
  • Type：Rotary Drilling Rig
  • Depth：200m
  • Hole Diameter：75-300mm
  • Mud Pump：Bw-160
  • Chassis：Trailer, Truck, Crawer Type

Base Info

  • Model NO.：XY-200T
  • Application：Water Well, Geological Exploration etc
  • Usage：Water Well
  • Power Type：Diesel
  • Transport Package：Standard Package
  • Specification：BV, SGS
  • Trademark：DEFY
  • Origin：Henan, China
  • Production Capacity：100 Sets Per Month

Description


1.Overall parametersDrilling depth200mMaximum open hole caliber300mmEnd hole caliber75mmDiameter of drill rod42,50mmDrilling angle90~75°2. Vertical Spindle Rotating speed71,142, 310,620r/minFeeding stroke450mmSingle line lifting capacity18 KNSteel Wire diameter10.3mmSteel wire capacity30mBrake diameter280mmmBrake width50mm4.Mud pump ModelBw-160Rate of flow160L/minWork pressure1.3 Mpa5.Power Diesel engine 22HP, 2200r/minElectrical motor15KW, 1460r/min
Company ability:
Since 1970s, Zhengzhou Defy has been one of the most powerful drilling rig manufacturers in China. In the meantime, she has large market share in Africa, Asia, South America, and other Europe areas, especially Kenya, Ghana, Tanzania, Chili. With average production of 200 set per month, Zhengzhou Defy has been one of the biggest exporters in China. She has earn her good reputation with high quality drilling equipment, systematic after sales service and sophisticated technical power.
Used Water Well Drilling Machine for Sale
Zhengzhou DEFY service:
Zhengzhou DEFY is proud to offer support through the entire process, including engineering, manufacturing, installation and commissioning. In addition, we provide drilling life-cycle services to our customers, including spare parts, technical support, overhaul/modifications and professional rig training.
Used Water Well Drilling Machine for Sale
Used Water Well Drilling Machine for Sale
